FONESTAR ARRAY-530 Instruction Manual

FONESTAR ARRAY-530 Instruction Manual

Compact line array system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RR Y-530
COMPACT LINE ARRAY SYSTEM
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARRAY-530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FONESTAR ARRAY-530

Summary of Contents for FONESTAR ARRAY-530

  • Page 1 RR Y-530 COMPACT LINE ARRAY SYSTEM INSTRUCTION MANUAL...
  • Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.

  • Page 3: Exemption Of Liability

    The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.
  • Page 4 INTRODUCTION Conventional loudspeaker systems are made up of a powerful loudspeaker or a set of them. A loudspeaker behaves as a precise sound source with 6 dB attenuation each time the distance from the source is doubled. Furthermore, a set of loudspeakers positioned vertically are not optimized so that the audio from each louds- peaker adds to the rest, producing a directivity pattern with lobes due to the audio cancellation being pro- duced.

  • Page 5: Controls And Functions

    DESCRIPTION The compact line array system is made up of: - Subwoofer. - 4 mid-treble loudspeakers. - Rigging system with upper mount, front and back joints, and quick safety pins. It provides maximum audio quality thanks to its excellent frequency response. Adjustable tilt in the mid-treble speakers to achieve uniform coverage in the audience zone.
  • Page 6 Use speaker cable with speaker connectors. ASSEMBLY STRUCTURE Due to the connection of the different elements of the ARRAY-530 (subwoofer and loudspeakers) the following possibilities are available in the same line combining a maximum of two ARRAY-530: - 1 subwoofer and 4 loudspeakers.

  • Page 7: Installation

    INSTALLATION The line array has two installation possibilities: 1) HANGING WITH THE RIGGIN G SYSTEM The most common and suitable way is to hang it with the rigging system. To do this, position and bolt the rigging system to the subwoofer in the following way: - Insert the eyebolts in the rigging system using the nuts and bolts supplied as accessories.
  • Page 8 Front link Back link Then, attach the first of the mid-treble loudspeakers to the subwoofer: - Attach a front link to the front of the subwoofer and attach it to the mid-treble loudspeaker using the quick safety pins as shown in the image. Note: the front links must be placed with the convex part towards the front of the array, as shown in the previous image.
  • Page 9 Join the rest of the mid-treble loudspeakers to each other in the same way. Join the front first, and then the back. The tilt of the mid-treble loudspeakers can be adjusted to vary the coverage angle and achieve uniform audio in the audience zone.
  • Page 10 Note: the front links must be placed with the convex part towards the front of the array. the back links must be positioned on the line array in the same direction as is printed on the back link itself. Therefore, the printing of the links will be visible on one side and not on the other.

  • Page 11: Technical Specifications

    TECHNICAL SPECIFICATIONS ARRAY-530 CHARACTERISTICS Compact LINE ARRAY system. Subwoofer and 4 mid-treble loudspeakers with adjustable tilt from 0 to 10º in steps of 2º. Manufactured in reinforced wood and finished in highly resistant granulated paint. Suspension system and accessories. For fixed or mobile installations.

  • Page 12: Warranty

    This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law “La Ley General para la Defensa de los...
