User instructions
Connecting an AUX source device
Using the supplied 3.5mm audio cable, it is possible to
connect an external audio device eg: mp3 player to the
CSPK258WWi.
1: Connect the 3 . 5 mm cable into the AUDIO input socket
(10) on the rear of the unit .
2: Connect the other end to your audio devices
headphone output or Line-out .
NOTE: The volume output is effected by the
volume level on the source EG: MP3 player, so
make sure that is set to about 70-80% ( not too
loud to avoid distortion).
NOTE: You will need to remove any docked iPod/
iPhone device to allow playback of the AUX input.
Powering on/off the speaker
1: Press & hold the ON/STANDBY button (2) to turn the
CSPK258WWi ON or press once to enter STANDBY .
NOTE: an indicator will light up to indicate the unit
is ON.
Adjusting the volume
1: Press the VOL- (3) or VOL+ (4) buttons to decrease or
increase the sound levels accordingly .
Troubleshooting
In the unlikely event of difficulties with your appliance
please follow the trouble shooting guide below .
If the problem persists, contact the retailer if the
machine is still under guarantee .
Customer helpline: 0870 600 3030
problem
Solution
Your iPod does not
• Make sure the dock insert is
dock properly
the correct one for your iPod .
• Make sure the system is
No Sound
plugged in, your iPod/iPhone
is turned on & is playing a
track .
• Remove your iPod/iPhone
from the dock, wait briefly,
then reset it . You may need
to do this a few times .
• Make sure you have the
latest software on your iPod/
iPhone .
No sound after
• Remove your iPod/iPhone
from the dock, wait 5s and
quickly dock/
undocking your
return to the dock .
iPod/iPhone
• Unplug the power cable for
1 minute then plug back in
again .
Technical specifications
Power supply • Mains adaptor : AC 100-240V~50Hz
• Mains adaptor output : DC 5V 1 . 5 A
• Battery : 4 x AA
Output power • 2 x 2W
