Pyle PPHP82LB User Manual page 3

1. DC 9V/1.5A input for PPHP62LB, DC 15V/2A input for PPHP82LB
2. Charge LED indicator
3. Power button
4. LED button
5. USB and Micro SD could support Mp3
6. 3.5MM audio input jack
7. 6.5MM microphone input jack
8. 6.5MM guitar input jack
9. Music volume knob
10. Play/Pause on USB/Micro SD mode, scan channel on FM mode
11. Last music on USB/Micro SD mode, last channel on FM mode
12. Short press for choosing di erent input signal, long press for voice cancel
function on USB/Micro SD/BT MODE
13. Mute function
14. Next music on USB/Micro SD mode, next channel on FM mode
15. Short press to repeat song function, press and hold for microphone priority
ON/OFF
16. Microphone volume control knob
17. Music treble control knob
18. Music bass control knob
19. Microphone echo control knob
20. Guitar volume control knob
Troubleshooting and Warning
Fault Possible Cause
1. No input sound source
No sound
2. Volume is too low
1. Volume too high
Distortion
2. Speaker may be damaged
of sound
1. Microphone plug is not fully
inserted.
Karaoke
2. Microphone switch is not on
does not
3. Microphone volume knob is
work at the lowest position
4. Wireless microphone has low
battery
1. The song format in the U disc
MP3
is incorrect
does not
2. Improper operation has caused
a process disorder
play
3. USB disc is disconnected
4
www.PyleUSA.com
Solution
1. Use a better music signal
2. Adjust volume
1. Turn down the volume
2. Repair or replace it
1. Plug microphone properly into
the socket
2. Turn on microphone switch
3. Adjust microphone volume
properly
4. Replace battery
1. Transform song format into
Mp3 format
2. Reboot the machine
3. Insert USB disc properly
PPHP82LB
8'' Portable Wireless PA System
2 Channel Wireless BT, TWS Function, USB/Micro SD/FM/Mic and Guitar Inputs
(1000 Watts)
Features:
•
TWS Function
•
1000 Watts of Peak Music Power Output
•
Includes Latest DJ LED Light
•
USB/Micro SD Card Reader/FM/Aux/MIC and Guitar Inputs
•
LED Display
•
ON/OFF Switch to Control Multi-Color Racing Lights
•
Built-in Rechargeable Battery
•
(2) 1/4'' -inch (6.5mm) Microphone/Guitar Instrument Inputs
•
Aux (3.5mm) Input Jack
•
Perfect for Karaoke, Parties, Conferences, Indoors/Outdoors and More
PPHP62LB
6.5'' Portable Wireless PA System
2 Channel Wireless BT, TWS Function, USB/Micro SD/FM/Mic and Guitar Inputs
(800 Watts)
Features:
•
TWS Function
•
800 Watts of Peak Music Power Output
•
Includes Latest DJ LED Light
•
USB/Micro SD Card Reader/FM/Aux/MIC and Guitar Inputs
•
LED Display
•
ON/OFF Switch to Control Multi-Color Racing Lights
•
Built-in Rechargeable Battery
•
(2) 1/4'' -inch (6.5mm) Microphone/Guitar Instrument Inputs
•
Aux (3.5mm) Input Jack
•
Perfect for Karaoke, Parties, Conferences, Indoors/Outdoors and More
This products can expose you to a chemical or group of checmicals, which
may include "Lead and lead compounds" which is known in the state of
California to cause cancer, birth defects, or other reproductive harm. For
more info, go to https://www.p65warnings.ca.gov/.
5
www.PyleUSA.com
