CONDOR
®
STOP! WARNING: READ THIS FIRST!
First read and understand the instruction manual and product labels for important safety, set-up and troubleshooting information. If you
have problems setting up or using the CONDOR® GD-3500 Garage Dolly Ramp, contact customer service at (815) 754-7418 or contact
us via email @ www.condor-lift.com. The CONDOR® GD-3500 Garage Dolly Ramp is not intended for use by children.

Assembly Instructions:

to assemble your CONDOR® GD-3500 Garage Dolly Ramp before beginning. In the unlikely event that you find a part damaged or
missing, please call customer service @ #1-815-754-7418.
Component Photo
1. The GD-RAMP can be placed on the rear of the GD-3500 regardless of the location of the rear wheel bracket.
Set the ramp down so that the holes line up over the tapped holes in the wheel bracket. Use the (2) Button Head
screws to attach the ramp to the dolly. Tighten the screws with the included hex key.
2. If you have purchase the additional Loader Ramp (SOLD SEPARATELY) you can insert it into the rear slot and
then rotate it down to lower it to the floor.
GD-3500 GARAGE DOLLY
Remove all parts from shipping box. Check the parts below to make sure you have all the parts needed
Item
A
B
C
RAMP USER INSTRUCTION MANUAL
Component Description
GD-3500 Ramp
(GD-RAMP1)
Hardware
(2) 5/16"x1" Button Head Screws
3/16" Hex Key
QTY
1
2
1
