ADC ClearGain Dual Inline TMAs Specification Sheet page 6

ClearGain
Americas
Dual Inline Power Distribution Unit Typical Specifications
ELECTRICAL
Input Voltage:
Output Voltage:
Maximum Current Draw:
PHYSICAL
Dimensions (HxWxD):
Weight:
Color:
CONNECTORS
Output for MHUs:
Power Connector:
General Alarm Connector:
General Communications Connector:
INDICATORS
ALARM OUTPUT
ENVIRONMENT
Storage:
Transportation:
Operation:
Housing:
Temperature Range (Indoor Use):
Lightning Protection:
APPROVALS
QUALITY
ACCESSORIES
Basic Accessories:
Optional Accessories:
O r d e r i n g I n f o r m a t i o n
Description
ClearGain Masthead Unit
Bias-T Kits*
7/16 DIN male to BTS, 7/16 DIN female to ANT
7/16 DIN female to BTS, 7/16 DIN male to ANT
N female to BTS, N male to ANT
N male to BTS, N female to ANT
Dual Inline Power Distribution Unit – Includes power cable and grounding cable
*Bias-T, DC Cable 4.25 meters (SMB to TNC), Grounding Cable 1.5 meters (one end terminated)
Approved for use with ADC supplied Masthead Units only.
w w w . a d c . c o m
Dual Inline TMAs
®
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
20-56 Vdc positive/negative ground
3x16 Vdc each
3A
43 x 196 x 103 mm
1 kg
Silver
SMB, male (qty 3)
4-pin male
3-pin male
3-pin male
Green OK/NOK LEDs
Red General Alarm LED
Alarm output is isolated 3-pin relay
connection. Normally open and
normally closed connection available.
ETS3019-1-1
ETS3019-1-2
ETS3019-1-3
IP40
-20°C to +65°C
IEC 1000-4-5 EMC
CE
MTBF 250,000
Manufactured under ISO 9001 quality system
Power supply cable (10 m), alarm cable (10 m),
communications cable (10 m), grounding cable (2 m)
and wall mounting screws
Mounting hardware for 19" rack mount
ADC is an active member
of the Antenna Interface
Standard Group.
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Catalog Number
CG0AWSDD155DT00
STRB-DM-DF-G-KIT
STRB-DF-DM-G-KIT
STRB-NF-NM-G-KIT
STRB-NM-NF-G-KIT
CG0000000000PFM
6
