B-14G and B-142G
Single or Double
Gas Boilerless Combination-Oven/Steamer
Shown with optional floor stand and casters
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Legs
4" (101.6mm) adjustable legs
6" (152.4mm) adjustable legs
6" (152.4mm) seismic legs
25" (635mm) adjustable legs
Floor stand with rack supports
Stand Mount Casters
Locking control panel
Locking door hasp
Tamper proof screws
Additional stainless steel wire shelves
Stainless steel back panel
Chicken roasting rack
Extended warranty
OPTIONS AND ACCESSORIES
(AT NO CHARGE)
LP gas
44 Lakeside Avenue, Burlington, VT 05401 • Phone: (802) 658-6600 • Fax: (802) 864-0183
Project
Item No.
Quantity
All data is shown per oven section, unless otherwise indicated.
Refer to operator manual specification chart for listed model name.
EXTERIOR CONSTRUCTION
Stainless steel top, front, sides and right hand door hinge
Aluminized steel bottom
Single pane tempered viewing window
Door mounted condensate trough
Well protected control panel
Side mount, easily adjustable door hinges
Roll out control panel exposes most serviceable parts
INTERIOR CONSTRUCTION
Fully welded stainless steel frame
Fully insulated cooking chamber
316L stainless steel oven cavity
Fixed drain bottom center of cavity
Filterless grease slinging convection fan
Easily removable stainless steel side rails
OPERATION
Boilerless steam generation
Standard control with four function selection switch for steam, hot air, com-
bined steam/hot air, cool down, Vario Steam® and steam on demand feature
Solid state rotary dial thermostat - range 150-500°F (66-260°C)
Motor driven 120 minute timer shuts down at elapsed time
Two speed fan
Magnetic door interlock switch shuts off oven when door is opened
Electronic ignition
Open vented system. Condenses steam and drains away by-products of the
cooking process, eliminates flavor transfer
11 rack positions with 1-5/8" (41mm) spacing
Oven clean light
Wall mounted filter system - Carbon Block and Scale Inhibitor
CAPACITY
Fourteen 12" x 20" x 2-1/2" deep pans at 3-1/4" spacing
Seven 18" x 26" deep pans at 3-1/4" spacing
STANDARD FEATURES
Five (5) stainless steel wire shelves per section (capacity for 7)
26" (660mm) legs with casters for B14G
6" (152mm) casters for B142G
Pressure spray bottle for oven cleaning
Hose and spray assembly for interior cleaning
Stacking kit and casters for double stack ovens
Water pressure regulator (1 per section)
Drain kit assembly
Start-up inspection service by factory authorized service agent
One year parts and labor oven warranty*
*
For all international markets, contact your local distributor.
BLODGETT COMBI
www.blodgett.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blodgett COMBI B-142G
Summary of Contents for Blodgett COMBI B-142G
- Page 1 Solid state rotary dial thermostat - range 150-500°F (66-260°C) Motor driven 120 minute timer shuts down at elapsed time Two speed fan Magnetic door interlock switch shuts off oven when door is opened Electronic ignition Open vented system. Condenses steam and drains away by-products of the cooking process, eliminates flavor transfer 11 rack positions with 1-5/8"...
-
Page 2: Oven Clearances
B-14G AND B-142G SHORT FORM SPECIFICATIONS: Provide Blodgett Combi model B-14G single or double, gas combination-oven/steamer. Unit shall have the ability to cook with pressureless steam, hot air, or combination of steam and hot air. Mechanical mode switch shall allow the operator to choose four modes, steam, hot air, combi or cool down mode. Timer to be 120 minute motor driven.
