CYPRESS LAKE 5 PIECE CUSHION SEATING SET
Questions, problems, missing parts with this product? Please contact us
at www.numarkcustomerservice.com
ACCESSORIES
Ja (1 spare)
Short Bolt
Jb (16 + 1 spare)
Medium Bolt
Jc (4)
Long Bolt
ITEM#SC-K-117SFE/5
SKU#810459659
1
Jd (16)
Metal Washer
Je (1)
Allen Wrench
