Tyco Electronics HVSA-3-1580S Series Manual

15kv class transition splice for 3/c pilc to 3/c armored extruded dielectric (poly/epr) power cables

Advertisement

Quick Links

Suggested Installation Equipment (not supplied with kit)
• Cable preparation tools
• Tyco Electronics P63 cable preparation kit or cable manufacturer
approved solvent
• Clean, lint-free cloths
• Non-conducting abrasive cloth, 120 grit or finer
• Electrician's tape
• Connector(s) and installation tools
• Tyco Electronics recommended torch
Safety Instructions
DANGER: When installing electrical power system accessories,
failure to follow applicable personal safety requirements and written
installation instructions could result in fire or explosion and serious
or fatal injuries.
To avoid risk of accidental fire or explosion when using gas torches,
always check all connections for leaks before igniting the torch and
follow the torch manufacturer's safety instructions.
To minimize any effect of fumes produced during installation, always
provide good ventilation of confined work spaces.
As Tyco Electronics has no control over field conditions which
influence product installation, it is understood that the user must
take this into account and apply his own experience and expertise
when installing product.
Customer Service
For 24 hour customer service, call 800-327-6996.
PII 54863
Revision AD
HVSA-3-1580S
15kV Class
Transition Splice for 3/C PILC to
3/C Armored Extruded Dielectric (Poly/EPR) Power Cables
Recommended Tyco Electronics Torches
Install heat-shrinkable cable accessories with a "clean burning" torch,
i.e., a propane torch that does not deposit conductive contaminants
on the product.
Clean burning torches include the Tyco Electronics FH-2629,
FH-2649 (uses refillable propane cylinders) and FH-2618A (uses
disposable cylinder).
Adjusting the Torch
Adjust regulator and torch as required to provide an overall 12- inch
bushy flame. The FH-2629 will be all blue, the other torches will have
a 3- to 4-inch yellow tip. Use the yellow tip for shrinking.
Regulator Pressure
FH-2618A
Full pressure
FH-2649
25 psig
FH-2629
15 psig
Cleaning the Cable
Use an approved solvent, such as the one supplied in the P63 Cable
Prep Kit, to clean the cable. Be sure to follow the manufacturer's
instructions. Failure to follow these instructions could lead to
product failure.
Some newer solvents do not evaporate quickly and need to be
removed with a clean, lint-free cloth. Failure to do so could change
the volume resistivity of the substrate or leave a residue on the
surface. Please follow the manufacturer's instructions carefully.
General Shrinking Instructions
• Apply outer 3- to 4-inch tip of the flame to heat-shrinkable material
with a rapid brushing motion
• Keep flame moving to avoid scorching
• Unless otherwise instructed, start shrinking tube at center,
working flame around all sides of the tube to apply uniform heat
To determine if a tube has completely recovered, look for the following,
especially on the back and underside of the tube:
1. Uniform wall thickness
2. Conformance to substrate
3. No flat spots or chill marks
4. Visible sealant flow if the tube is coated
Note: When installing multiple tubes, make sure that the surface of
the last tube is still warm before positioning and shrinking the next
tube. If installed tube has cooled, re-heat the entire surface.
1
PCN 504819-000
Effective Date: June 29, 2010

Advertisement

loading
Need help?

Need help?

Do you have a question about the HVSA-3-1580S Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tyco Electronics HVSA-3-1580S Series

  • Page 1 Recommended Tyco Electronics Torches • Cable preparation tools Install heat-shrinkable cable accessories with a “clean burning” torch, • Tyco Electronics P63 cable preparation kit or cable manufacturer i.e., a propane torch that does not deposit conductive contaminants approved solvent on the product.
  • Page 2: Installation Instructions

    Installation Instructions 1. Product selection Check kit selection with cable diameter dimensions in Table 1. Note: Table is for 100% insulated Poly cable. For 133% insulated cable, check actual cable dimensions. Table 1 PILC/Poly PILC Poly Nominal Insulation Insulation Maximum Connector Cable Diameter Diameter...
  • Page 3 Choice 2 If Drain Wire Shield Cable Refer to Table 2 and prepare the cables as shown. Remove any 4" fillers to the armor cutback. Pull drain wires back to Dimension B (102mm) and temporarily tape over ends as shown. Bend back the grounding PILC conductors(s) over the jacket as shown.
  • Page 4 Choice 2 1/2" (10mm) Belt Papers If Belted PILC Cable PILC Remove belt papers as shown. Go to Step 7. Lead Sheath Paper Insulation 7. Mark insulation as shown HVSA-3-1581S 3-1/2” (89mm) HVSA-3-1582S 4” (102mm) PILC HVSA-3-1583S 5” (127mm) HVSA-3-1584S 5-1/2”...
  • Page 5 12. Mark OBT/ Insulation at “I” HVSA-3-1581S 6-1/2” (165mm) HVSA-3-1582S 7” (178mm) PILC HVSA-3-1583S 8” (203mm) HVSA-3-1584S 8-1/2” (216mm) OBT/Insulation 13. Position black conductive tubes; shrink in place Place black conductive tube over each phase and position at dimension “I”. Shrink in place starting at the end nearest to the center of the splice.
  • Page 6 18. Mark lead sheath as shown 1-1/2" (40mm) Note: To ensure SRM to OBT adhesion, gently heat the SRM insert and adjacent OBT before moving on to the next step. PILC Lead Sheath 19. Install oil seal Stretch SRM to 1/2 Original Width Remove backing from one side of a long strip of SRM.
  • Page 7 23. Remove insulation Refer to Table 5 and cut back the insulation as shown. Table 5: Connector Dimensions Expansion Max Length Max O.D. Gap “X” "Z" "Y" "X" HVSA-3-1581S 4-1/2” (114mm) 0.90” (23mm) 1/4” (5mm) Insulation 1/2 Length Expansion HVSA-3-1582S 5-1/2”...
  • Page 8 28. Apply SRM at semi-con cutback Stretch SRM to 1/4" (5mm) wide Remove backings from the short angle-cut piece of SRM. Place tip of SRM at semi-con step and tightly wrap to fill the step. Overlap semi- con and insulation and taper down to meet insulation as shown. Note: If using UniShield* cable, apply SRM as shown to fill 1/4"...
  • Page 9 32. Position red insulating tubes; shrink in place Center tubes over the black stress control tubes. Shrink in place using the same method as in Step 31. Red Insulating Tube 33. Apply red sealant Red Sealant Red Sealant Remove backing from red sealant. Using light tension, wrap sealant over the cable, butted against the red insulating tube as shown.
  • Page 10 36. Install ground Choose the appropriate cable type (Choice 1-3) and follow the directions given to ground each phase. Choice 1 Ground Braid Connector If Drain Wire or UniShield Cable Pigtail the shield wires and crimp on to the ground braid using the connectors provided.
  • Page 11 39. Install armorwrap Clean Jacket Clean Jacket (200mm) 8" (200mm) 8" Position armorwrap around splice area and center on the exposed cable armor and lead sheath. PILC Bind the ends of the armorwrap to the cable armor and lead sheath with the tape provided.
  • Page 12 However, Tyco Electronics Corporation has no control over the field conditions which influence product installation. It is the user’s responsibility to determine the suitability of the installation method in the user’s field conditions. Tyco Electronics’ only obligations are those in Tyco Electronics’ standard Conditions of Sale for this product and in no case will Tyco Electronics be liable for any other incidental, indirect or consequential damages arising from the use or misuse of the products.
