Tyco Electronics FIST-MB2-T Installation Instruction

Medium box for cable termination
Hide thumbs
Table of Contents

Advertisement

Quick Links

Contents
Medium Box for Cable Termination
1 Introduction
1.1 Product description.
2 General
2.1 Tools
3 Installation and pre
assembling of box
1
Introduction
1.1
Product Description
The FIST-MB2-T is a Generic Box for a fiber management system that offers the function of splicing and patching.
It provides a mechanical and environmental protection for all the fiber optic components and permits easy
access by both the network provider and the customer. The box is applicable indoor and inside street cabinets.
The FIST-MB2-t box is designed to terminate, and patch fibers, it can handle up to 16 connectors.
2
General
2.1
Tools
Hammer
Screwdriver
Marker
Fiber guiding pin
FACC-tube-cutter-01
FIST-GB-CUT-TOOL-PG16
FACC-TUBE-Stripper-02
FACC-HEAT-GUN-220V or 110V 1460W hot air gun
FIST-MB2-T
I N S T A L L A T I O N
5.4 installation of the pigtail seals
to cut loose tubes
to cut holes for glands
to strip loose tubes
to install the heatshrink cable seals
I N S T R U C T I O N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FIST-MB2-T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tyco Electronics FIST-MB2-T

Summary of Contents for Tyco Electronics FIST-MB2-T

  • Page 1: Table Of Contents

    Introduction Product Description The FIST-MB2-T is a Generic Box for a fiber management system that offers the function of splicing and patching. It provides a mechanical and environmental protection for all the fiber optic components and permits easy access by both the network provider and the customer. The box is applicable indoor and inside street cabinets.

  • Page 2: Kit Contents

    Installation Kit contents Preparation of box 3.1.1 Unlock the screws and remove the cover. Depending on the network layout and the construction of the used cables, the kit content may be different. Some of the components will be pre-assembled in the box depending on the selection and the ordering.

  • Page 3: Opening Of The Ports

    Opening of the cable ports 3.2.2 Select the appropriate gland depending on the cable diameter. 3.2.3 Install the glands in the selected ports by tighten the nut on the inside of the box, do not forget to install the rubber ring on the outside of the box.

  • Page 4: Installation Of Wraparound Groove Plates

    Installation of wraparound groove plates Mounting of the box on the wall 3.3.1. Take the groove plates and slide the long protrusions into the left bracket of the UMS bracket. 3.5.1. Place the template against the wall and mark the selected mounting positions onto the wall.

  • Page 5: Cable Installation

    Cable installation For slotted core cable only Cable preparation 4.1.1. Feed the cable through the cable port gland. 4.1.3.1 Install a protection tube of 150 mm over the fibers of each slot and slide it into the slot of the cable. 4.1.2.

  • Page 6: Cable Termination

    Cable termination 4.2.3 Secure the cable with a tiewrap onto the cable attachment plate. 4.2.1 Pull the cable back in the correct position, the cable jacket should protrude 30 mm into the box. passing the cable strapping point. 4.2.4 Tighten the gland Routing of cable fibers 4.3.1 Allocation of the tubes in the tube holders.
  • Page 7 4.3.3 Mark the tubes between the two marks on the tube holder. 4.3.5 Position the loose tubes in the tube holder and slide the tube holder retainer with the snap forwards in the lowest possible cavity of the tube holder above the loose tube(s). The tube holder retainer must snap.

  • Page 10: Pigtail Installation

    4.3.7 Pull gently on the fibers in the tray and make sure that the 5.1.2 When all adapters are installed slide them to the left side of the fibers are well contained in FAS block and wraparound groove plate. patch panel, measure the length of the Anti Movement Strip and cut the AMS to length (distance of the opening minus 6 slots).

  • Page 11: Installation Of Pigtails With Kevlar Termination

    5.2.3 Pull the pigtails for 2000 mm through the patch panel and mark them. 5.1.5 Remove the pigtail gland seal and nut , feed the jumper connectors through the gland and mount the connectors to the adapter on the patch panel. Installation of pigtails with Kevlar termination unit 5.2.4 Remove the pigtail jacket up to the mark.

  • Page 12: Pigtail Routing To The Splicing Trays

    5.2.7 Close the KTU connector by snapping the lid, and pull on the 5.3.2 Store the pigtails temporary on the tray. Kevlar to slide the inner part backwards as far as possible. Installation of pigtail gland seals 5.2.8 Cut the Kevlar yarns at the connector and install in the patch panel adapter.

  • Page 13: Fiber Organisation After Splicing

    Closing the box 5.4.3 Tighten the gland nut on the pigtail seal. Fiber organisation on trays after splicing Install the FAS block cap and the retainer. Take the splice protector and put it centered towards the splice holder. Different types of splice holders can be fitted in the tray with the use of an adapted splice holder.

  • Page 14: Important Steps

    In case of a box with lock insert first the four guiding pins in the box before installing the cover. Important steps during installations • Make sure that grooves on FAS and wraparound groove plate are clean. • Clean the fibers •...
  • Page 16 Conditions of Sale for this product and in no case will Tyco Electronics be liable for any incidental, indirect or consequential www.tycoelectronics.com damages arising out of the sale, resale, use or misuse of the product. Users of Tyco Electronics products should make their own evaluation to determine the suitability of each such product for the specific application.
