Tyco Electronics Raychem FIST-MB2-S Installation Instruction

Fist medium box for cable splicing only
Hide thumbs
Table of Contents

Advertisement

Quick Links

Contents
FIST Medium Box for Cable Splicing Only
1 Introduction
1.1 Product description
2 General
2.1 Tools
2.2 Kit contents
3 Installation and pre
assembling of box
3.1 Preparation of box
3.2 Opening of the ports
3.3 Installation of wrap around groove
plates
3.4 installation of the splicing trays
3.5 Mounting of the box on the wall
1 Introduction
1.1 Product Description
The FIST-MB2-S is a Generic Box for a fiber management system that offers the function of splicing cables to
cables. It provides a mechanical and environmental protection for all the fiber optic components and permits
easy access by both the network provider and the customer. The box is applicable indoor and inside street
cabinets.
The FIST-MB2-S box is designed to splice fibers and can handle 96 splices (fully occupied by SE-trays).
2 General
2.1 Tools
Hammer
Screwdriver
Marker
Fiber guiding pin
FACC-tube-cutter-01
FIST-GB-CUT-TOOL-PG16
FACC-TUBE-Stripper-02
FACC-HEAT-GUN-220V or 110V 1460W hot air gun
FIST-MB2-S
I N S T A L L A T I O N
4 Cable installation
4.1 Cable preparation
4.2 Cable termination
5. Fiber routing to individual trays
5.1 Allocation of the loose tubes in the tube holder
5.2 Routing of the cable fibers
6 Fiber organisation after splicing
7 Closing the box
8 Important steps
9 Rearrangements
to cut loose tubes
to cut holes for glands
to strip loose tubes
to install the heatshrink cable seals
I N S T R U C T I O N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Raychem FIST-MB2-S and is the answer not in the manual?

Questions and answers

Related Manuals for Tyco Electronics Raychem FIST-MB2-S

Summary of Contents for Tyco Electronics Raychem FIST-MB2-S

  • Page 1 FIST-MB2-S I N S T A L L A T I O N I N S T R U C T I O N FIST Medium Box for Cable Splicing Only Contents 1 Introduction 4 Cable installation 1.1 Product description 4.1 Cable preparation 4.2 Cable termination 2 General...
