Introduction Thank you and congratulations on the purchase of your new Model H / X Foldable Power Chair. It is important that you read through this manual before operating your chair - so, please take that time. You will find instructions and recommendations for easy operation of your Model H / X Foldable Power Chair. -
Page 5: Product Specifications
Ground clearance to foot rest 2.5" Model X front/rear wheels 6”/12” Model H front/rear wheels 6"/26" Wheel Material - Model X Front (Solid) rear (Air) Wheel Material - Model H Solid, Polyurethane Incline/Slope Capability 8 Degrees Motor (2) 250W Brushless Motors Brakes Electromagnetic... -
Page 6: Safety, Operation & Setup
● The Model H/X should be adjusted to fit your needs. ● Make sure to take your time to learn how the Model H/X works before you begin riding. ● Practice bending, reaching and transferring in and out of the Model H/X. -
Page 7: Tie Down System
The Model H/X is not approved to be used with any tie down system, generally used to transport a seated user and power chair in a motor vehicle. ● Never sit in the Model H/X while in a moving vehicle. In an accident or sudden stop you may be thrown from the Power Chair. -
Page 8: Cornering Information
● Move yourself as close as you can to the object you wish to reach ● Turn off all power to the Model H/X before reaching ● Firmly grasp an armrest with one hand. This will help to prevent a fall if the Model H/X tips Cornering Information Always slow down while moving through a corner. -
Page 9: Environment & Everyday Use
Model H/X to tip forward ● Be mindful of any side hills as tipping is an issue ● Your Model H/X is not designed to drive up or down a curb or step more than 1/2 inch high ○... -
Page 10: Braking System
Model H/X will stop when the joystick is back at the default position (center/stop position). WARNING : Before standing up or sitting down from the Model H/ X chair you must manually engage both breaks. The breaks can be found above and to the side of the rear tires (See image below) Not engaging the breaks may cause the Model H/X roll from under you. -
Page 11: Armrests
Armrests The Model H/X armrests are designed to flip up. N ever lift the Model H/X by its armrests. Flip Back arms Setting up your Model H / X Unboxing the Model H / X Given the size and weight of box, we recommend two people work on unboxing this item. - Page 12 #5. Seat and back cushions #6. Batteries* #7 Charger #8 anti Tippers (recommended upgrade) *Note: Most Model H/X ship with the batteries installed. However, some Model H/X will ship in two boxes: main unit/ cushions/ charger and batteries . JDY Imports...
- Page 13 #10. your chair should be fully open #11. Slip on the seat and back and secure it with the velcro underneath the cushions Slip in the battery underneath the seat Make sure to Firmly press down the battery all the way. JDY Imports 323-522-5817 Page 12...
- Page 14 2. The 3rd wire attaches to the battery the Controller The main unit controller comes ready for a right-handed user. With a little rearranging, the Model H/X can be setup for a left-handed user as well. JDY Imports 323-522-5817 Page 13...
-
Page 15: Installing The Controller
#1. From the factory setup for right handed users. #2. Available option for left handed setup. #3. Seatbelt is attached to the chair. #3. Untighten he knob that secures the joystick JDY Imports 323-522-5817 Page 14... - Page 16 Attach the Cord into the Clips running to the back of the chair Before folding the chair make sure to release the back handleBar You can also remove the handleBar with a simple screw driver. JDY Imports 323-522-5817 Page 15...
-
Page 17: Batteries & Charging
Attached the first two parts of the cord (#1 and #2), then insert into the battery. Charging Tips & Notes ● The Model H/X comes with one (1) 24V 6Ah / 10Ah lithium ion batteries. They are partially charged. JDY Imports... - Page 18 ● Do not charge more than 6 hours to 8 hours. ● If you do not operate the Model H/X for two months, we recommend that you charge the battery for 6-8 hours before use.
-
Page 19: Operation And Installation
Operation and Installation Your Model H/X comes with one battery. Several things to note: ● Battery may be installed upon delivery or they may arrive in a separate box. ● Replacement batteries are available. Please call for more details. Gently slide the battery into the slots... -
Page 20: Controller
● To stop, just bring the joystick back to the initial position ● Getting into the Model H/X ○ Before sitting, make sure the Model H/X is p owered off , this will ensure the Model H/X will not move upon touching the joystick... - Page 21 The App will allow you to c ontrol all the settings on your Model H/X chair, including steering and driving sensitivity and speed, the app gives you real time information on your battery life, mileage and many other key indicators.
-
Page 22: Batteries
● Only use batteries approved and supplied by our company. Our batteries are special lithium batteries designed specifically for the use with the Model H/X. ● You must charge the battery for 6 to 8 hours before attempting to operate your Model H/X for the first time. - Page 23 NOTE: Do not use any parts or components unless they have been authorized in writing by a representative of our company. Battery installation The Model H/X comes with a V6 Battery or with an upgraded V10 battery ( costs extra) Gently slide the battery into the slots...
-
Page 24: Anti Tippers
Take the strap and make sure its tightly secure Anti Tippers Bothe the model H and the Model X have optional anti tippers. Anti tippers help the chair from falling backwards- we highly recommend that you buy anti tippers for the Model H/X JDY Imports... -
Page 25: Seat Design & Materials
Fasteners Many of the screws, bolts and nuts on the Model H/X are special high-strength fasteners. Replacing these fasteners with non-approved parts may cause your Model H/X to result in faulty operation and may cause harm to you or other people, therefore: 1. -
Page 26: Change & Adjustments
Change & Adjustments Never use non-Model H/X parts or make changes to your Model H/X unless authorized in writing by a representative from our company. Doing so will void the Warranty and may create a safety hazard. Before each use of the Model H/X : ●...
