CHLOE
36"
MODEL: 036036-L
036036-R
note:
For installing under counter sink with
counter stop
SteP 1:
Apply adhesive caulking around the
topside of rim near the edge. Carefully raise
sink in place, align, and press firmly
See Figure 1.
SteP 2:
Attach 4 undermount-clips to hold
lavatory in place
See Figure 2.
SteP 3:
Secure top & back splash to cabinet
by using adhesive caulk
See Figure 3.
INSTALLATION GUIDE
INSTALLATION SHEET
Figure 1.
Counter Top
Adhesive Caulking
Figure 2.
Figure 3.
Adhesive Caulking
ronbow.com
Modular Collection
Back Splash
Undermount Clip
RONBOW CORP
