- Page 1 Monitoring Cassette PSCU 6000 CLASS Phone: +49 (0) 911 / 703 8877 Grundig SAT Systems GmbH Fax: +49 (0) 911 / 703 9210 Beuthener Strasse 43 E-mail: info@gss.de D-90471 Nuremberg Internet: http://www.gss.de...
-
Page 2: Table Of Contents
o n t e n t s 1 Safety regulations and notes ................ 3 2 General information ..................4 Packing contents ................4 Meaning of the symbols used ............4 Technical data ................4 Description ...................6 Software query................7 3 Assembly ....................8 Setting the signal paths ..............8 Positioning of the jumpers ...............9 Blockdiagram................9 Audio and video signal "internal"... -
Page 3: Safety Regulations And Notes
• Test the software versions of the head-end station and the cassette and update them if necessary. The current software versions can be found at "www.gss.de". Take action to prevent static discharge when working on the device! Electronic devices should never be disposed of in the household rubbish. In... -
Page 4: General Information
e n e r a l i n f o r m a t i o n aC k i n g C o n t e n t s 1 Monitoring Cassette PSCU 6000 1 Brief assembly instructions e a n i n g o f t h e s ym b o l s u s e d Important note —>... - Page 5 Measurement output Output impedance: ................. 75 Ω Measuring range tolerance : ............± 3 dB Adjustment: ................> 9.5 dB Decoupling (measurement output on measurement input): ....30 dB Loop-through loss: ..............–2 … 5 dB Video and Audio output Video output impedance: ..............75 Ω Video output voltage: ..............1 V Audio output impedance: ..............1 kΩ...
-
Page 6: Description
PC and the PSW 1000 software. For this observe the operation instruction of the PSW 1000 software, to be downloaded from our home page "www.gss.de". To operate this cassette the software version of the control unit must be "V 44"... -
Page 7: Software Query
o f t wa r e q u e ry Control unit If necessary, you can activate the indication of the software version of the control unit manually: • Press any two keys on the control unit of the head-end station simultaneously until the display goes dark and the software version, e.g. "V 44" appears. Cassette See chapter "Querying the software version", page 19. - 7 - PSCU 6000... -
Page 8: Assembly
s s e m b l y e t t i n g t h e s i g n a l Pat h s The signal paths are adjustable via jumpers. Note Take action to prevent static discharge when working on the device. Danger of cut injuries! The cassette is made of punched stainless steel parts. -
Page 9: Positioning Of The Jumpers
os i t i o n i n g o f t h e j u m P e rs Jumpers —> The position of the jumpers meets the "internal" setting. lo C k d i ag r a m Audio Infokanal Video... -
Page 10: Audio And Video Signal "Internal
" " u d i o a n d v i d e o s i g n a l i n t e r n a l For this positioning of the jumpers (factory setting) the AUDIO VIDEO internal signals are used only. internal internal The info channel is provided via the measuring out-... -
Page 11: Installing The Cassette
—> The info channel is not available. • Push the cassette cover from the back of the cassette into the guides and fasten it with the 3 screws (see page 8). n s ta l l i n g t h e C a s s e t t e – Ensure the head-end station is mounted so it will not be able to vibrate. Avoid, for example, mounting the head-end station onto a lift shaft or any other wall or floor construction that vibrates in a similar way. -
Page 12: Emc Regulations
r e g u l at i o n s To comply with the current EMC regulations, it is necessary to connect the lines leading in and out of the head-end station using cable terminals. When mounting the cassette in a head-end station which is installed in a 19" cabinet, make sure the connections leading in and out for the 19"... -
Page 13: Overview Of The Cassette
—> The operating software of the cassette can be updated via the 9-pin D-SUB socket "RS-232" using a PC or notebook and the software "BE-Flash". You can find the current operating software on the website "www.gss.de". - 13 - PSCU 6000... - Page 14 —> To transmit alarm messages, we recommend to connect the cassette to a corresponding management unit via the "RS 232" socket. Ad- ditionally the cassette can be configured using a PC or laptop and the PSW 1000 software. • The "START/SEARCH" button starts the channel search of the cassette (see chapter 6, page 22).
-
Page 15: The Control Panel At A Glance
h e C o n t r o l P a n e l a t a g l a n C e e n u i t e m s Program the cassette using the buttons on the control unit of the head-end sta- tion. -
Page 16: Programming
r o g r a m m i n g r o g r a m m i n g P r o C e d u r e BE–Remote V 44 Ein / On please wait … t > 10 s Box 1 Messcass. -
Page 17: Programming The Cassette
r o g r a m m i n g t h e C a s s e t t e —> Pressing the button for longer than 2 seconds cancels the programming procedure. This takes you back to the programme item "Selecting the cassette"... -
Page 18: Output Channel
• Press the button. —> The "Output channel" – "OUTPUT:" menu is activated. u t P u t C h a n n e l In this menu you set the output channel of the cassette. In addition you get access to the submenus for querying the software version and setting the fine- tuning. -
Page 19: Switching The Modulator Off Or On
• Press the button. —> The "Output channel" – "OUTPUT:" menu is activated again. i n e t u n i n g Only change the fine-tuning in exceptional circumstances (e.g. moiré, interfer- ences), since once you change it, all connected television sets of the cable system must be adjusted to match it by means of corresponding fine-tuning corrections. -
Page 20: Modulation Depth (Residual Carrier)
—> The "Modulation depth" – "MODULAT: Depth:" menu is activated. o d u l at i o n d e P t h r es i d ua l C a r r i e r If the sound drones due to the picture content, the modulation depth can be lowered. Box 1 MODULAT: Depth: -10%... -
Page 21: Setting "Extended
"extended" e t t i n g Besides the channel "Kanal" and the station name for analog stations or the symbol rate (e.g. 6,900 Ms = 6.900 MSymb/s) for QAM channels the dis- play mode "extended" shows the bit error rate "BER" of the transport stream and the signal level of the channels in dBµV. Kanal Name dBµV BR-3 514,00 6,900 Ms 1e-7 674,00... -
Page 22: Put The Cassette Into Operation (Channel Search)
u t t h e C a s s e t t e i n t o o P e r a t i o n C h a n n e l s e a r C h To ensure a high measurement accuracy for the channel search, the cassette must be in operation for about 30 minutes. - Page 23 If "Err."(Error) is displayed in column BER, the digital TV channel was detected, but is not locked at the moment. Picture on the display (menu setting "extended"): Kanal Name dBµV C 27 BR-3 514,00 6,900 Ms 1e-7 674,00 6,900 Ms 1e-7 850,00 6,900 Ms 1e-7 514,0 MHz S e i t e 1/1...
-
Page 24: Channel And Frequency Table
h a n n e l a n d f r e q u e n C y t a b l e CCIR – Band IV/V C 21 471.25 474.00 C 33 567.25 570.00 C 45 663.25 666.00 C 58 767.25 770.00 C 22 479.25 482.00 C 34 575.25 578.00 C 46 671.25 674.00... - Page 25 Declaration of CE conformity - 25 - PSCU 6000...
- Page 26 Service: Phone: +49 (0) 911 / 703 2221 Fax: +49 (0) 911 / 703 2326 Email: service@gss.de Änderungen vorbehalten. Technische Angaben ohne Gewähr. © by GSS GmbH V23/20092011...
