- Page 1 ME 200...
-
Page 2: Table Of Contents
o n t e n t s 1 Important safety information ..................3 2 Description .......................4 3 Overview .........................5 4 Operation ........................7 Basic Operation ..................7 Setup (Setting) ..................7 Device Setup ....................8 Time ......................8 System .....................8 Option .....................9 Picture .....................9 Upgrade / Backup ..................10 Software Update – USB Upgrade ..............10 Backup and Restore .................11 Backup.....................11 Restore .....................11... -
Page 3: Important Safety Information
m p o r t a n t s a f e t y I n f o r m a t I o n • Assembly, installation and servicing must be carried out by an authorised electrician. • Check the system for short circuits in the coaxial cables before starting up. •... -
Page 4: Description
C r I p t I o n ME 200 is a simple digital satellite instrument for DVB-S/S2. - Spectrum analyzer with level measurement (dBµV or dBm). - Constellation diagram with C/N, BER, FEC, MER and Modulation display. -
Page 5: Overview
v e r v I e w 9 10 11 12 13 23 24 25 26 Power on/off (hold depressed for 3…4 seconds) Power indicator Charging control red = charging in progress / green = finished flashing = accumulator error Indicator LED: LNB voltage 13 V on Indicator LED: LNB voltage 13 V on Indicator LED: LNB 22 kHz on... - Page 6 Selection buttons / OK = confirm Use the buttons to navigate through the menus. OK button selects/confirms input (calling the channel list in TV mode). Number buttons Hold the "•" button depressed for 3...4 seconds to switch the LCD dis- play on/off.
-
Page 7: Operation
p e r a t I o n 4.1 B a s I C p e r at I o n Use buttons to navigate through the menus. Use button OK to activate menu items respectively confirm inputs. Press the "EXIT" button to …... -
Page 8: Device Setup
e v I C e e t u p Switch on/off the (keyboard) Lighting, the Loudspeaker, the Keypad Tone, the LED Display as well as Cable Check. The Cable Check function checks the cur- rent of the signal cable to identify/distin- guish a multiswitch or LNB. -
Page 9: Picture
In the menu item Restore Factory Default you can reset the device to the factory settings. Menu item Information shows the current software version. p t I o n In the OSD Language menu item, set the language displayed in the menus. In the Subtitle Language menu item, select the preferred language. -
Page 10: Upgrade / Backup
4.3 u / B p g r a D e aC k u p Software updates as well as backups and restores are possible via the UPGRADE menu. – usB u o f t wa r e p Dat e p g r a D e •... -
Page 11: Backup And Restore
aC k u p a n D es to r e In the menu Software Update > DB Management you can backup all settings as well as restore the settings. aC k u p • Insert a USB stick into the USB socket of the ME200. -
Page 12: Measuring Instrument
4.4 m e a s u r I n g n s t r u m e n t The SATELLITE and FINDING menus are available for measurements. sateLLIte The SATELLITE menu provides access to the SPECTRUM, SAT SETUP, COMPASS, ANGLE CALCULATION and CONSTELLATION sub- menus. -
Page 13: Sat Setup
• Use button to change the sampling frequency. • Press to pause the measuring process. • Use button 1 to select a DiSEqC signal (N=off, position 1...4). • Use button 2 to switch the 22kHz signal on/off. • Use button 3 to switch the polarity (13V/18V). •... -
Page 14: Angle Calculation
angLe CaLCuL atIon In the ANGLE CALCULATION menu, you can calculate the azimuth (degree indica- tion for alignment with a compass) and elevation (inclination) depending on your position for a satellite. • Enter the correct degrees of longitude and latitude of your location. •... -
Page 15: Constellation
ConsteLL atIon Here you can first select between Analyze by Frequency (selection via satellite and transponder) or Analyze by Program (se- lection of stored channels). Analyze by Frequency • Via Analyze by Frequency you can se- lect the satellite and the transponder number. -
Page 16: Finding
fInDIng The menu starts with the last used channel. • You can set any satellite/transponder with the buttons . Press the OK button to display selection options in tabular form. —> If an unlocked signal is detected, only the signal strength is dis- played. -
Page 17: Satellite Receiver
4.5 s at e L L I t e e C e I v e r e n u r o g r a m The PROGRAM menu contains the settings for the satellite receiver. h a n n e L ta B L e The Program Edit menu item contains a ta- ble with all channels found in the SAT SETUP... -
Page 18: Epg - Electronic Program Guide
epg - e L e C t r o n I C r o g r a m u I D e Via the menu item EPG you call up the Electronic Program Guide, which dis- plays the program contents of the activated channel in a table. •... -
Page 19: Sort
• Press the OK button to save the timer. • Use button to edit an already programmed timer. • Use the button to delete a timer. For the timer function, the device must remain switched on. o r t In the Sort menu, you can specify the order of the channels according to cer- tain criteria (Default - channel table, By Encrypt, By Freq, By Service Name). -
Page 20: 4.6 Multimedia
4.6 muLtImeDIa The MULTIMEDIA menu allows you to play back media content stored on a USB mem- ory device and connected to the USB port, as well as TV programs recorded with the ME200 (PVR = personal video recorder). When you call up the MULTIMEDIA button of the MAIN MENU, the USB menu is dis- played first. -
Page 21: Movie Configuration
ov I e o n f I g u r at I o n Here you can set how subtitles should be displayed. pvr C o n f I g u r at I o n Here you can make settings for a USB stor- age medium on which the TV channel is to be recorded. -
Page 22: Music
u s I C Start the music browser with the button Use the and OK buttons to navigate through the folder structure of the storage medium. Use the RECALL button to return to a higher level in the folder structure. If music files (MP3, wma, ogg) are found in a directory, you can select them and press the OK button to start playback. -
Page 23: Film
I L m Start the film browser with the button Use the and OK buttons to navigate through the folder structure of the storage medium. Use the RECALL button to return to a higher level in the folder structure. If video files (MP4, avi, 3gp) are found in a directory, you can select them and press the OK button to start playback in preview mode. -
Page 24: Specifications
Audio formats ................MP3, wma, ogg Pictures ..................bmp, jpg, png Packing contents ME 200, Charger, Bag, Strap, AV cable, F adapter, Brief assembly instructions DiSEqC™ is a registered trading name of Eutelsat GSS Grundig Systems GmbH • Beuthener Straße 43 • D-90471 Nuremberg Phone: +49 (0) 911 / 703 8877 •...
