Rear Mounting Instructions
Step 1: Following OEM instructions, remove
the child restraint brackets on the passenger
and driver side of the vehicle. Retain the
hardware and the child restraint bracket.
Step 2: Secure each mounting bracket to
the metal frame using the provided 1/4"x 20
hex head bolts. Insert the hex head bolts
through the bottom holes on each side to
fasten the light bar frame to the mounting
brackets (See page 13 for vehicle specific
bracket diagram).
Step 3: Position the opening of each
bracket directly under the mounting location
for the removed child restraint bracket.
Certifications:
CE Certified
SAE J595 Certified
Meets CCR, Title 13 Requirements
Fusion Specifications
Voltage:
Power
Dimensions:
8
F E NIE X . 2017 I NST RU CT ION MA N UA L
WE B. w w w.feni ex .co m
9-13 VDC
< 5 Amps
0.93"H x 37"W x 5.5"H
Shown (upside
Passenger
Bracket
TM
V2.0
Charger Full
Rear Model
down)
Driver
Bracket
