6.3 neoVI FIRE 2 Ethernet Cable Adapter Connector Pinouts and Signal
Mapping
This secondary cable usually sits between the RAD-Galaxy Ethernet Cable Adapter and
conventional networks, and is described further in Section 2.4. Its HD-26F connector attaches
to the HD-26M on the RAD-Galaxy Ethernet Cable Adapter, and thus has the same pinout as
shown in Table 5. Below are the pinouts for the other connectors on this cable (DB-25M, DB-
9M and RJ-45F) as well as cable signal mapping table.
DB-25M Connector
The DB-25M connector has the pin assignments shown in Table 9, with pin numbering for the
connector illustrated in Figure 82.
Table 9: neoVI FIRE 2 Ethernet Cable Adapter DB-25M Connector Pinout.
Version 1.2 - November 28, 2017
RAD-Galaxy User's Guide
Pin # Name
HS CAN 7 H /
1
SW CAN
2 N/C
HS CAN 6 H /
3
SW CAN 2
4 HS CAN 6 L
5 MS CAN H
6 MS CAN L
7 HS CAN 7 L
8 LIN
9 DNC
10 DNC
11 DNC
12 DNC
13 GND
14 HS CAN 1 H
15 HS CAN 1 L
16 HS CAN 2 H
17 HS CAN 2 L
18 HS CAN 4 H
19 HS CAN 3 H
20 HS CAN 3 L
21 HS CAN 5 H
22 HS CAN 5 L
23 HS CAN 4 L
24 DNC
25 V BATT
Description
High Speed CAN channel 7, high /
Single Wire CAN channel 1
No connection
High Speed CAN channel 6, high /
Single Wire CAN channel 2
High Speed CAN channel 6, low
Medium Speed CAN channel, high
Medium Speed CAN channel, low
High Speed CAN channel 7, low
LIN channel (also Ethernet Activation for DoIP)
Do not connect
Do not connect
Do not connect
Do not connect
Ground
High Speed CAN channel 1, high
High Speed CAN channel 1, low
High Speed CAN channel 2, high
High Speed CAN channel 2, low
High Speed CAN channel 4, high
High Speed CAN channel 3, high
High Speed CAN channel 3, low
High Speed CAN channel 5, high
High Speed CAN channel 5, low
High Speed CAN channel 4, low
Do not connect
DC Input Power
