AUTOPILOT SYSTEM

DESCRIPTION

The Flight Control system is an integrated 3-axis autopilot and flight
director, containing automatic elevator trim control. The system is
configured for dual flight directors and is certified for ILS Category 2
operations.
The system consists of the following:
Two FGC-3000 Flight Guidance Computer Module (2)
One FGP-3000 Flight Guidance Panel (1)
SVO-85C Primary Servo (2)
SMT-86C Servo Mount (2)
SVO-85B Primary Servo (1)
SMT-86B Servo Mount (1)

FGS MODES

Flight Guidance Mode Selection

The primary means of selecting and deselecting flight guidance modes
is by pressing the appropriate button on the FGP. pressing an FGP
button when the mode is not selected will select the mode. A
subsequent press of the FGP button deselects the mode. The FGS
defaults to the basic lateral and vertical flight guidance modes when no
modes are selected by the FGP.
10 Sep 2006
Section VII
Systems
VII-22-1
