WHAT YOU'LL NEED
Drill
Socket Set
Ladder
Mallet
Forklift / Crane / Scissor Lift *
Tape Measure
String-line
Level
Marking Pencil
Stanley Knife
Allen Key (supplied)
Warning read instructions carefully before use.
Recommended procedure to follow in this document.
For safety reasons it is recommended that four persons set up
any Crest Tent.
Ensure area is free from any sharp objects and overhead objects.
(888) 201 1968
www.extremecanopy.com
Advertisement
Related Manuals for Extreme Canopy CREST
Summary of Contents for Extreme Canopy CREST
- Page 1 Warning read instructions carefully before use. Recommended procedure to follow in this document. For safety reasons it is recommended that four persons set up any Crest Tent. Ensure area is free from any sharp objects and overhead objects. (888) 201 1968...
- Page 2 CREST TENT OVERVIEW 2. Structure Description 1. Introduction The Extreme Canopy Crest main structure is made up of extruded aluminum and steel. The adjustable frame Base Plate can be used on any ground surface. Frame Specifications Max Allowed Windspeed: 50mph (80km/hr)
- Page 3 Part Description Part Description Part Description 3. Part Description Part Description Part Description Part Description Description Pcs. Description Pcs. Description Description Pcs. Pcs. Description Description Pcs. Pcs. Ridge connector M10*70 Screw Description Pcs. Description Pcs. Item # Ridge connector Description Ridge connector Item # Description...
- Page 4 Cement: Dynabolt Fix each Base Plate with Dynabolts. When the Crest Tent is in use and if part of the structure looks damaged or not fit for purpose the Tent should be dismantled Weight Plate: Ground Mounting (suitable for any surface) at once for safety reasons.
- Page 5 All ‘S’ serials tent are modular unit with 3 meters bay distance, which can extend unlimited. Construction 5. Construction When commencing construction of the Crest Tent build each All ‘S’ serials tent are modular unit with 3 meters bay distance, which can extend unlimited. Refer to the Elevation Drawing and Parts List to confirm your frame bay section flat on the ground.
- Page 6 pright connector and roof beam ut the base plate into the corner upright as seen Put corner connector into corner upright and rawing A. Fixed by a M10*120 screw. roof beam, fixed by M10*70 screw. Step 3: Assemble ridge connector with roof beams Refer to the Elevation Drawing and Parts List to confirm your Step 1: Assemble base plate (5) and corner Step 2: Assemble corner upright, corner...
- Page 7 Refer to the Elevation Drawing and Parts List to confirm your method of construction for Step 6. Gable Eave Rail Roof Purlin Gable Support Eave Purlin Step 7: Assemble gable support (9) and STEP 7: Step 7: Assemble gable support (9) and Assemble Gable Support and Gable Eave Rail STEP 6: Step 6: Assemble eave purlin (6) and roof...
- Page 8 ground condition) drawing G. Same way for the oth Note: Fixation by expansion bolt (for cement ground), steel stake (for earth ground, grass ground) and weight bracket (for various ground which can suffer a certain weight pressure). Step 8: Frame fixation (The frame must be fixed well prior to install fabric) According to the ground condition, adjust the place of corner support, make it vertica STEP 8: and then fix the base plate on the ground.
- Page 9 special e fabric n pulling STEP 12: STEP 9: Fix Thread Bracing and Tension Bar Installation of Roof Fabric Insert the Tension Bar into the sleeve of the Roof fabric the correct Connect the Ropes to the Webbing on Roof Panel. way as shown in drawing (12a) .
- Page 10 When the Crest Tent is in use and if part of the structure looks damaged or not fit for purpose the marquee should be dismantled at once for safety reasons. Wall Tension Bar...
