Blodgett Pitco B16-PF45 Specification Sheet

B16-PF45 and B20-PF65
Deep Sectional Fryers
by
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Flue riser
24"
36"
Baskets
Extra single basket (full size) for 14" pot
Extra twin size basket for 14" pot
Fryer filter system
Stainless steel frypot cover
Stainless steel sides
Stainless steel divider
Heat lamp over drain cabinet
Cable restraint kit
OPTIONAL OIL FILTRATION
Simple two step operation: Step 1, open blue handle
valve to drain oil into filter pan. Step 2, open red handle
valve to return oil from filter to fryer.
Self-aligning filter piping makes it easy to assemble and
disassemble
Larger 3" (7.6 cm) drain line allows for faster draining
without clogging
Light weight, removable filter pickup assembly, with built-
in handle, for fast media cleaning under busy conditions
High flow pump and large return lines produce faster oil
refill times
Large filter media collects more debris, which extends
time between changes.
B16-PF45 shown
.
Project
Item No.
Quantity
Model B16-PF45 (16" wide, 45 pound capacity)
Model B20-PF65 (20" wide, 65 pound capacity)
The Blodgett Sectional Deep Fryers are available with two riser heights. An
optional rearward-extending flue riser is available to increase the overall
depth to match a deep battery. Battery-design assistance is available!
SPECIFY
Gas Type Natural Gas
Manifold Front (1-1/4")
Flue Riser Height 24" (option)
Range Depth Standard
Position in Battery Left End
Operating altitude (if above 2000 ft (700 meters) _____________________
Blodgett can often accommodate special or custom requirements. Contact
your Blodgett representative.
STANDARD CONSTRUCTION (
Frypot: 16 gauge, type 430 #3 welded tank with extra smooth peened finish
ensures easy cleaning. Long-lasting, high temperature alloy stainless steel
heat baffles are mounted in the heat exchanger tubes to provide maximum
heating and combustion efficiency. Front access, quick opening 1-1/4" drain
valve
Gas Control System: Includes manual shut-off, 100% safety shut-off pilot gas
filter, pilot adjustment and 200° to 400° adjustable thermostat. High limit control
automatically shuts down main burner and pilot if oil temperature exceeds 475°F.
STANDARD FEATURES (
New Pitco Solstice burner/baffle design increases cooking production, lowers
flue temperature, improves working environment and generates more produc-
tion per BTU
Quick recovery is provided to eliminate waiting between loads
Available in 45lb and 65lb capacity
9" front rail to match sectional range
Stainless steel tank and cabinet
Two twin plated, mesh fry baskets with plastic coated, heat resistant handles
Wide spacing tube frypot allows more heat to be transferred to oil and easy
cleaning
1-1/4" full port drain valve helps eliminate clogging
Large cold zone captures food particles, reduces flavor transfer and extends
oil life
Single unit combination gas shut-off, pressure regulator and pilot ignition sys-
tem
6" adjustable legs front, 6" fixed casters rear
100% safety shut off
Warranty: two year parts and labor from date of purchase
1100 Old Honeycutt Road Fuquay-Varina, NC 27526 USA
Phone: (877) 255-3976 • Fax: (866) 644-1354
Propane
Rear (1")
36" (option)
Deep (option)
Right End
)
All models
)
All models
BLODGETT
www.blodgett.com
Not at End
