Model B16-FR45 and B20-FR65

Model B16-FR45

Improper installation, adjustment, alteration, service or maintenance can cause property damage,

injury or death. Read the installation, operating and maintenance instructions thoroughly before

1184959

ANUAL

$18.00

OPERATOR'S MANUAL

installing or servicing this equipment.

1100 Old Honeycutt Road, Fuquay-Varina, NC 27526

www.blodgettrange.com

WARNING

IMPORTANT FOR FUTURE REFERENCE

Please complete this information and retain this

manual for the life of the equipment:

Model #: ___________________________

Serial #: ___________________________

Date Purchased: ____________________

Model B20-FR65

SECTIONAL DEEP FRYER

MANUAL SECTION SR

Table of Contents

Need help?

Do you have a question about the B16-FR45 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blodgett B16-FR45

Page 1 Model #: ___________________________ Serial #: ___________________________ Date Purchased: ____________________ OPERATOR’S MANUAL Model B16-FR45 and B20-FR65 Model B16-FR45 Model B20-FR65 WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
Page 2 NOTICE Blodgett Range Sectional Deep Fryers are intended for commercial use only. Not for household use. Warranty will be void if service work is performed by other than a qualified technician, or if other than genuine Southbend replacement parts are installed.
Page 3: Table Of Contents
MODEL NUMBERS This manual is for the Blodgett Range Sectional Deep Fryer models B16-FR45 and B20-FR65, which can be ordered with a front-to-back depth of 36" or 42". The serial plate is located inside the front door on the left side.
Page 4: Specifications
PECIFICATIONS ECTIONAL RYER PECIFICATIONS DIMENSIONS OF MODEL B16-FR45 Top View Front View Side View Width Depth Height Front Gas Connection Rear Gas Conn. Depth Crated Option Weight 16.0" 31.8 36.0" 6.0" 30.0" 36.0" 54.0" 33.8 27.8 33.5 9.5" 2.0" 219 lbs 36"...
Page 5 PECIFICATIONS ECTIONAL RYER DIMENSIONS OF MODEL B20-FR65 Top View Front View Side View Width Depth Height Front Gas Connection Rear Gas Conn. Depth Crated Option Weight 20.0" 31.8 36.0" 6.0" 30.0" 36.0" 54.0" 33.8 27.8 33.5 12.8" 4.5" 229 lbs 36"...
Page 6 BTUs/Hour Natural 4" W.C. 35,000 140,000 #36 - 0.1065" dia. Main Propane 10" W.C. 30,000 120,000 #52 - 0.0635" dia. B16-FR45 Natural 4" W.C. #77 - 0.0180" dia. Pilot Propane 10" W.C. 0.0110" dia. Natural 4" W.C. 35,000 175,000 #38 - 0.1015" dia.
Page 7: Installation
NSTALLATION ECTIONAL RYER NSTALLATION NOTICE Installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1, Natural Gas Installation Code, CAN/CGA-B149.1, or the Propane Installation Code, CAN/CGA-B149.2, as applicable. NOTICE These installation procedures must be followed by qualified personnel or warranty will be void.
Page 8 NSTALLATION ECTIONAL RYER Step 2: Install Flue Riser The flue riser assembly is packed separately in the shipping crate. Attach the flue riser to the top rear of the fryer as shown in the illustration below. Flue Riser Front Gas Manifold Connection (both sides)
Page 9 NSTALLATION ECTIONAL RYER Step 3: Install the Legs (or Casters) and Restraint A set of legs or casters is packed with the fryer. A threaded pad is fastened to the base frame at each corner (see illustration on page 8). Each leg or caster has a similar mating thread. When casters have been ordered, the casters are provided with a Zerk fitting for proper lubrication when required.
Page 10 (natural gas or propane). The fryer should be connected ONLY to the type of gas for which it is equipped. All Blodgett Range equipment is adjusted at the factory; however, pilot height should be checked at installation and adjusted, if necessary (see page 24).
Page 11 NSTALLATION ECTIONAL RYER CAUTION ALL PIPE JOINTS AND CONNECTIONS MUST BE TESTED THOROUGHLY FOR GAS LEAKS. USE ONLY SOAPY WATER FOR TESTING ON ALL GASES. NEVER USE AN OPEN FLAME TO CHECK FOR GAS LEAKS. ALL CONNECTIONS MUST BE CHECKED FOR LEAKS AFTER THE UNIT HAS BEEN PUT INTO OPERATION.
Page 12 NSTALLATION ECTIONAL RYER Step 6: Check Clearances and Ventilation Select a firm, level location for your fryer. Leave clearance, whenever possible, so that access from the rear is possible to permit cleaning. If the unit is to be set on non-combustible flooring, such as a concrete slab, 3 inches minimum toe room must be provided to prevent restriction of the air opening in the bottom of the unit.
Page 13 NSTALLATION ECTIONAL RYER Step 7: Check Installation CAUTION IF YOU SMELL GAS DURING THE LIGHTING PROCEDURE, IMMEDIATELY SHUT OFF THE GAS SUPPLY UNTIL THE LEAK HAS BEEN CORRECTED. The following items should be checked by a qualified service technician before or within the first 30 days of operation: 1.
Page 14: Operation
These procedures must be followed by qualified personnel or warranty will be voided. The Blodgett Range Sectional Deep Fryer is an immersion tube fryer. This is the most efficient method of transmitting heat into the oil. The tubes are actually large heat exchangers. Each tube is heated by a burner at its front that propels its flame and heat into the tube, toward the rear, where it is vented into a flue box.
Page 15 2. When the fryer is new, fill the frypot with water and clean thoroughly (see “Weekly Cleaning” on page 20) in order to remove protective coatings and any foreign matter. 3. The recommended solid shortening capacity for the fry pot is 45 pounds for model B16-FR45 units and 65 pounds for model B20-FR65 units.
Page 16 PERATION ECTIONAL RYER AUTOMATIC PILOT VALVE The Automatic Pilot Valve provides an automatic safety shutoff for the fryer when the pilot flame is extinguished. When the pilot flame is burning, the valve is held open electromagnetically by the electrical current from a thermopile in the pilot flame. When the pilot flame goes out, generation of current ceases and the valve closes automatically.
Page 17: Cooking Hints
OOKING INTS ECTIONAL RYER OOKING INTS USER TIPS • Smoking oil means that the temperature is too high, or that the oil has broken down. • Gum in frypot denotes a need for thorough cleaning (see “Weekly Cleaning” on page 20) •...
Page 18 OOKING INTS ECTIONAL RYER FRYING DON’TS • Don’t turn on the fryer with no shortening in the frypot. • Don’t fill the frypot above the line on rear of frypot. • Don’t allow oil in frypot to fry down to the point where there is insufficient oil in which to fry a full load. •...
Page 19: Cleaning
RYER LEANING Blodgett Range equipment is constructed with the best quality materials and is designed to provide durable service when properly maintained. To expect the best performance, your equipment must be maintained in good condition and cleaned daily. Naturally, the frequency and extent of cleaning depends on the amount and degree of usage.
Page 20 2. Have your Authorized Service Agent or another qualified service technician clean and adjust the unit for maximum performance. Consult the Authorized Parts/Service Distributor list for the Authorized Service Representative in your area or contact Blodgett Range at 1-800-348-2558. CLEANING STAINLESS STEEL SURFACES To remove normal dirt, grease and product residue from stainless steel use ordinary soap and water (with or without detergent) applied with a sponge or cloth.
Page 21 LEANING ECTIONAL RYER Darkened areas, called “heat tint,” sometimes appear on stainless steel surfaces where the area has been subjected to excessive heat. These darkened areas are caused by thickening of the protective surface of the stainless steel and are not harmful. Heat tint can normally be removed by the above cleaning techniques, but tint which does not respond to that procedure calls for a vigorous scouring in the direction of the polish lines, using SCOTCH-BRITE scouring pads or a STAINLESS scouring pad in combination with a powered cleanser.
Page 22: Service
ERVICE ECTIONAL RYER ERVICE NOTICE Warranty will be void and the manufacturer is relieved of all liability if: (A) Service work is performed by other than a qualified technician, (B) Other than genuine factory replacement parts are installed. WARNING Adjustments and service work may be performed only by a qualified technician who is experienced in, and knowledgeable with, the operation of commercial gas cooking equipment.
Page 23 ERVICE ECTIONAL RYER CHECKING AND ADJUSTING PRESSURE REGULATOR The combination gas valve and pressure regulator is factory set at 4" W.C. for natural gas and 10" W.C. for propane gas. To check the manifold pressure, do the following: 1. Turn thermostat “OFF” (lowest position) and combination gas valve knob to the “PILOT” setting. 2.
Page 24 CONVERTING FROM NATURAL GAS TO LP GAS Obtain a natural-to-LP gas conversion kit (Southbend part number 4440499) from your authorized Blodgett Range parts distributor. The kit comes with five LP gas orifice spuds (of which four are used by a model B16- FR45 and five by a model B20-FR65).
Page 25 ERVICE ECTIONAL RYER TROUBLESHOOTING Problem Likely Cause Burners do not come on Gas supply to unit off. Combination gas valve is in “OFF” or “PILOT” position. Pilot not ignited. Thermostat not “ON.” Pilot will not stay ignited Combination gas valve is in “OFF” position. Pilot gas not adjusted properly.
Page 26 ERVICE ECTIONAL RYER Wiring Diagram GAS INLET REGULATOR ADJUSTMENT COMBINATION GAS VALVE PILOT GAS PILOT PILOT ADJUSTMENT THERMOPILE COMPONENT LEADS REGULATING LIMITING THERMOSTAT THERMOSTAT Notes: 1. High limit switch is set to 450 ° F. 2. Voltage measured across TH/PP and TP with main burner on should be greater than 100 mV. ’...
Page 27: Parts
Index of Parts Diagrams Page Number Description Frypot Parts for Model B16-FR45 Frypot Parts for Model B20-FR65 Cabinet Parts for Model B16-FR45 Cabinet Parts for Model B20-FR65 Gas Train Parts for Model B16-FR45 Gas Train Parts for Model B20-FR65 ’ 1184959 PERATOR ANUAL...
Page 28 ARTS ECTIONAL RYER Frypot Parts for Model B16-FR45 Part Number Description 1182221 Frypot weld assembly 1182262 Baffle weld assembly 1182238 Valve, ball, 1-1/4 in 1036618 Thermostat bulb clamp 1140700 Screen, tube, 14" fryer P9181 Basket, fryer, 14", single 1176845 Drain pipe extension...
Page 29 ARTS ECTIONAL RYER Frypot Parts Model B20-FR65 Part Number Description 1182005 Frypot weld assembly 1182021 Baffle weld assembly 1176853 Valve, ball 1036618 Thermostat bulb clamp 1140701 Screen, tube, 18" fryer P9183 Basket, fryer, 18", single 1176845 Drain pipe extension 1176846 Clean out rod (optional) * not shown on drawing.
Page 30 ARTS ECTIONAL RYER Cabinet Parts for Model B16-FR45 See drawing on following page. Part Number Description 1-2849 Knob, door 2391 Cabinet door assembly 1164132 Door striker 1164133 Catch, door 2835 Body front 1164541 Valve panel 1182138 Manifold assembly, complete 1182372 Cover subassembly, 16"...
Page 31 ARTS ECTIONAL RYER Cabinet Parts for Model B16-FR45 See parts list on previous page. ’ 1184959 PERATOR ANUAL...
Page 32 ARTS ECTIONAL RYER Cabinet Parts for Model B20-FR65 See drawing on following page. Part Number Description 1-2849 Knob, door 1183730 Door assembly, complete 1164132 Door striker 1164133 Catch, door 1183724 Body front 1183722 Valve panel 1183709 Manifold assembly, complete 1183740 Cover subassembly, frypot 1183761 Filler, rear 65lb...
Page 33 ARTS ECTIONAL RYER Cabinet Parts for Model B20-FR65 See parts list on previous page. ’ 1184959 PERATOR ANUAL...
Page 34 ARTS ECTIONAL RYER Gas Train Parts for Model B16-FR45 See drawing on following page. Part Number Description 1165400 Rear gas bracket (for units with optional rear gas connection) 1163527 Tail pipe (for units with optional rear gas connection) 1146905 Elbow, st. black., 1" 90 deg (for units with optional rear gas connection)
Page 35 ARTS ECTIONAL RYER Gas Train Parts for Model B16-FR45 See parts list on previous page. ’ 1184959 PERATOR ANUAL...
Page 36 ARTS ECTIONAL RYER Gas Train Parts for Model B20-FR65 See drawing on following page. Part Number Description 1183744 Support, rear gas (for units with optional rear gas connection) 1183743 Nipple, pipe, blk 1" x 28" (for units with optional rear gas connection) 1146905 Elbow, st.
Page 37 ARTS ECTIONAL RYER Gas Train Parts for Model B20-FR65 See parts list on previous page. ’ 1184959 PERATOR ANUAL...
Page 38 ECTIONAL RYER Notes: ’ 1184959 PERATOR ANUAL...
Page 39 ECTIONAL RYER Notes: ’ 1184959 PERATOR ANUAL...
Page 40 Model B16-FR45 and B20-FR65 SECTIONAL DEEP FRYER A product with the Blodgett Range name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this unit. When service is needed, contact an Authorized Service Agency or your dealer.
