SPECIFICATIONS

ANALOG SOUND ENGINE
SOURCES: VCO 1, SUB 1, SUB 2 / VCO 2, SUB 1, SUB 2
FILTER: Self-Oscillating Ladder Filter, Low-Pass, 4-Pole (-24 dB/Octave)
ENVELOPES: VCA EG (Attack, Decay); VCF EG (Attack, Decay)
ANALOG SEQUENCERS (x2)
STEPS: 4 Steps per Sequencer, selectable Quantization
CLOCK: Driven by any and all of the Rhythm Generators
RHYTHM GENERATORS (x4)
RHYTHM: Derived by dividing the Tempo by an integer value (1-16)
CLOCK: 20 BPM to 3,000 BPM (Beats Per Minute; 1 Pulse Per Quarter-note), MIDI Clock, EXT CLOCK
PATCHBAY
JACKS: 32 x 3.5mm
INPUTS: 17 Input Jacks
OUTPUTS: 15 Output Jacks
REAR PANEL
AUDIO: 1⁄4" TRS Headphone or 1⁄4" TS Instrument
POWER: Power Supply connection
SECURITY: Kensington Lock slot
DIMENSIONS
SIZE (WxDxH): 12.57" x 4.21" x 5.24"
WEIGHT: 3.5 lbs
POWER SUPPLY (INCLUDED)
STYLE: Wall adapter; barrel connection; center-pin positive
INPUT: 100 – 240VAC; 50 Hz – 60 Hz
OUTPUT: +12VDC; 1200mA
POWER CONSUMPTION
TYPICAL: 4.8 Watts
EURORACK SPECS
CURRENT DRAW: 360mA (maximum) from +12VDC (10-pin header)
MOUNTING DIMS: 60HP (1"/26mm Module Depth)

ACCESSORIES

The following accessories are available for purchase at authorized Moog dealers:
2-TIER VERTICAL RACK KIT
3-TIER VERTICAL RACK KIT
GIG BAG
6" 3.5 mm CABLE PACK (QTY 5)
12" 3.5 mm CABLE PACK (QTY 5)
EMPTY 60HP CASE
EMPTY 104HP CASE
BACKUP POWER SUPPLY
