Summary of Contents for Vimar Elvox 6837/C17
- Page 1 Installer guide 6837/C17 Interphone power supply 117V 60Hz 30W...
- Page 2 CSA product is according to UL 6500 Description of symbols shown in the power supply. double square: it is a class II power supply triangle with ligthning: hazard of electric shock, dangerous voltage; Triangle with exclamation mark: danger, pay attention. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN...
- Page 3 INSTALLATION RULES. Installation should be carried out observing current installation regulations for electrical systems in the Country where the products are installed. Ensure clearance around the appliance so there is sufficient ventilation. There must be no dripping or splashes of water on the appliance. WARNING: To prevent injury, the appliance must be secured to the wall as described in the installation instructions.
- Page 4 WIRING DIAGRAM FOR 2-WIRE (1+n) DOOR ENTRY SYSTEM WITH CONVERSATION PRIVACY N.B.: This installation may be carried out also with interphones Art.0875/037, (8877) and/or Art.0900/137 without conversation pri vacy. To enable the conversation privacy on interphone Art. 6201 desconnect the “ A ” jumper and connect the Art. 7155 card. A - Entrance panel with speech unit Mains Series 1300, 1200, 3300, 8000, 8100, PATAVIUM...
- Page 5 ADJUSTMENTS P1 - Adjustment of lock activation time (preset during manufacturing). P2 - Volume adjustment of speech unit P3 - Adjustment of lock activation time REMOVABLE TERMINAL BLOCKS TECHNICAL CHARACTERISTICS OF POWER SUPPLY ART. 6837/C17 Power supply in grey ABS housing; preset for mounting on cases with 12-module DIN support - 117V A.C.
- Page 6 VERSIONS FROM STANDARD WIRING DIAGRAMS VERSION 1 Connection of landing call push-button. When activating the landing call push-button the phone sounds with a tone different from the one obtained by the external entrance panel call. MAINS Outdoor push-button POWER SUPPLY Art.
- Page 7 VERSIONS FROM STANDARD WIRING DIAGRAMS VERSION 3 Connection of stair-lighting push-button by using repeater relay Art. 0170/001. N.B.: To switch on stair-light press push-button with bulb symbol . The maximum capacity of the phone button contacts is 24V 0.5A A.C./D.C. MAINS RELAY Art.
- Page 8 Vimar SpA: Viale Vicenza, 14 36063 Marostica VI - Italy Tel. +39 0424 488 600 - Fax (Italia) 0424 488 188 49400807A0 00 1503 Fax (Export) 0424 488 709 VIMAR - Marostica - Italy www.vimar.com...
