Emist EM360 Quick Start Manual

EM360™ Electrostatic Sprayer Quick Start Guide
Thank you for choosing the EMist EM360™ Electrostatic Sprayer. We have created
an easy to use system that combines advanced liquid application technologies with
improved mobility. The result is superior application and enhanced disinfection, as
well as a convenient convertible design for users.
CONTENTS: After unpacking, inspect the components for any damage or missing
hardware pieces, etc. The following components are included with your purchase:
1) Power Pack with Applicator
2) One Gallon Liquid Tank
3) Rechargeable Battery
4) Battery Charger (220v optional)
1
Step 1: Install the Battery
Make sure the battery is fully charged. (5 bars = full charge)
•
With the power pack battery slots facing you, remove the battery covers by pinching the triangle.
•
Install the battery with the tab facing left.
•
Gently push the battery to seat it.
•
Replace the battery cover.
•
Step 2: Liquid Tank Insertion
For the initial set up/test, fill the liquid tank 1/3 full with water.
•
Gently place the liquid tank in the power pack.
•
Slightly rotate clockwise about 1/4 turn while depressing the tank until you feel resistance. The tank's handle should
•
line up with placard on the power pack.
Step 3: Pull Cart Installation (Optional)
Raise the adjustable clamp, place the power pack with the battery slots facing the handle.
•
Put the clamp over the hand grip of the power pack, keeping the quick connect cable out of the way. This secures
•
the pack in place.
Adjust the pull cart handle to your comfort.
•
Step 4: Grounding Strap Installation (Optional)
Identify the white portion of the grounding strap ring and install it by placing the white portion on the ball of the foot.
•
Place the elastic strap around your heel.
•
Snap the button to the bottom of the power pack.
•
Step 5: Power Pack Harness Strap Adjustments (Optional)
• Put the harness on the power pack.
Put the power pack on like you would a backpack and adjust the straps to fit comfortably.
•
2 3
5) Grounding Strap
6) Backpack Harness with Holster (Optional)
7) Pull Cart with Holster (Optional)
4 5 6 7
