ADC Wireless Repeaters InterReach Specification Sheet page 3

InterReach
Mobile TV In-Building Repeater
GUI Features
Automatic Level Control (ALC)
The system will control the output power to
maintain the stability and protect the unit.
RSSI Indicator
Optimize and ease donor antenna placement
during installation.
Isolation Check
The device offers an isolation check configurable in
the GUI when the system is set up and powered on.
Typical Specifications
RF SPeCIFICAtIOn
Operating Frequency for the 700 MHz
Down Link:
Output Power:
Gain:
Flatness:
Out of Band Gain:
nOISe FIGURe
Up Link:
VSWR:
Frequency Stability:
ALC:
Gain Control Range:
Delay:
Supply Voltage:
Current Consumption:
enVIROnMentAL
Operating temperature:
Humidity
InDICAtORS/COntROLS
USB Port:
LeD:
tX Shutdown:
Isolation:
DC Power:
RSSI Indicator:
PHYSICAL
Donor Antenna:
Service Antenna:
Dimensions (WxHxD):
Weight:
Mounting or Installation:
w w w . a d c . c o m
Wireless Repeaters
®
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
User-friendly Interface
USB connection allows you to control:
• adjust gain
• perform system test and calibration
Over Power Shut Down
The system can detect excessive power and will
shut down after 5 seconds to protect the unit.
Recheck occurs after 5 minutes and the system will
automatically resume operation when normal power
levels are reached.
6 MHz channel selective
716-722 MHz (ch 55), 722-728 (ch 56), 728-734 (ch 57)
+13 dBm
80 dB
±2 dB Full Band
65 dB Offset 1 MHz; 55 dB Offset 5 MHz
5 dB max
1.5 max
±0.05 ppM max
20 dB min
30 dB min; .5 dB Step
5 usec max
6 V
AC 110~220V to DC 6V SMPS Adaptor
3A max
DC 6V Current Consumption
-5°C ~ +40°C
85%
Gain, system test, calibration
Off (normal operation), red (alarm)
Yellow flashing (test), solid yellow (alarm)
Green (normal operation)
Thresholds measured at donor port
No LED <-105 dBm input
1 LED >-105 dBm input
2 LED >-95 dBm input
3 LED >-85 dBm input
N Type Female
N Type Female
150 x 200 x 67 mm (5.9 x 7.8 x 2.6 in.) including wall mount bracket
1.79 kg (3.95 lbs.)
Wall mount
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1 3
