Unpacking the Junos Space JA1500 Appliance
The Junos Space JA1500 appliance is shipped in a cardboard shipping container and
is secured with foam packing material. The container also includes an accessory box.
The items, listed in Table 1 are included in the JA1500 appliance box:
Table 1: Items in the JA1500 Appliance Shipping Container
Component
Junos Space JA1500 appliance chassis (See Parts of the Junos Space JA1500
Appliance)
Power cable
Mounting kits
RJ 45 to DB 9F cable with adapter, 7 ft. Console cable
7-foot, blue, Category 5e cable
Null modem serial cable
USB restore media Fflash drive
Security Products Safety Guide
CAUTION: The JA1500 appliance is maximally protected inside the shipping container.
Do not unpack it until you are ready to begin installation.
WARNING: The JA1500 appliance weighs over 27 lbs. (approximately 12.2 Kg). Use
correct lifting technique when moving the appliance.
To unpack the appliance, follow these steps:
Move the shipping container to a staging area as close to the installation site as
1.
possible, but where you have enough room to remove the system components.
Position the container so that the arrows are pointing up.
2.
Open the top flaps on the shipping container.
3.
Remove the accessory box and verify the contents against the parts inventory
4.
on the label attached to the container.
Pull out the packing material holding the appliance in place.
5.
Read the "General Safety Guidelines and Warnings" document with particular
6.
attention to "Chassis Lifting Guidelines."
Unpacking the Junos Space JA1500 Appliance
Quantity
1
1
2
1
2
1
1
1
1
