Operation, Repair, Parts
LazerVac
Vacuum for collection of dry concrete and asphalt dust. For professional use only.
Vacuum
Model 25M860 - LazerVac 550 (gasoline)
Separator
Model 25M862 - Cyclone 32 (32 gallon)
Important Safety Instructions
Read all warnings and instructions in this manual before using the
equipment. Be familiar with the controls and the proper usage of the
equipment. Save these instructions.
LazerVac 550
™
and Cyclone
www.graco.com/techsupport
3A5577C
Cyclone 32
EN
Advertisement
Table of Contents
Related Manuals for Graco LazerVac 550 25M860
Summary of Contents for Graco LazerVac 550 25M860
- Page 1 Model 25M862 - Cyclone 32 (32 gallon) Important Safety Instructions Read all warnings and instructions in this manual before using the equipment. Be familiar with the controls and the proper usage of the equipment. Save these instructions. LazerVac 550 Cyclone 32 www.graco.com/techsupport...
-
Page 2: Table Of Contents
Graco Standard Warranty ........ -
Page 3: Warnings
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable. - Page 4 Warnings WARNING FIRE AND EXPLOSION HAZARD Flammable fumes in work area can ignite or explode. To help prevent fire and explosion: • Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present.
-
Page 5: Battery Disposal
Battery Disposal Battery Disposal Do not place batteries in the trash. Recycle batteries according to local regulations. In the USA and Canada call 1-800-822-8837 to find recycling location or go to www.call2recycle.org. 3A5577C... -
Page 6: Component Identification
Component Identification Component Identification LazerVac 550 Cyclone 32 Parts List Component Component Vacuum Outlet Air Filter Housing Main Housing (contains Filter Bags) Diffuser Separator Lid Engine Choke, Fuel Valve, and Throttle Control Long Vacuum Hose (to connect the LazerVac or Engine Cyclone to the GrindLazer) Electric Start Key... -
Page 7: Setup
Setup Setup 2. Connect hoses. 1. Install dust collection bags onto vacuum and into separator. If using a Cyclone separator: a. Slide the Vacuum Dust Collection Bag onto the • Connect one end of the Short Vacuum Hose to the inlet of the LazerVac. -
Page 8: Operation
Operation Operation 4. Turn the Electric Start Key to START. 1. Slide the Fuel Valve on the engine to ON. 5. After the engine warms up, move Engine Choke to open and adjust the Throttle Control to the desired speed. 2. -
Page 9: Emptying Collection Tanks And Bags
Operation Emptying Collection Tanks and LazerVac Bags 1. When Vacuum Collection Bag has collected approximately 45 lbs (20 kg) of dust, the bag should be replaced. Momentarily pull down on the Vacuum Release Handle, then turn the LazerVac off. 2. Pull down on the continuous bag to expose 6 - 12” DUST HAZARD (15 - 30 cm) of new, unused bag. -
Page 10: Shutdown And Storage
Shutdown and Storage Shutdown and Storage Shutdown Storage 1. While the engine is running, momentarily pull down Slide Fuel Valve on the engine to OFF. Store indoors. on the Vacuum Release Handle. NOTICE Do not store in a location with high temperatures or excessive humidity, in order to prevent damage to your LazerVac components. -
Page 11: Maintenance And Repair
Maintenance and Repair Maintenance and Repair Weekly Inspect seals for damage. If damaged, replace seal. Ensure seals are installed correctly and properly sealed. To reduce the risk of serious injury: • Respirator must be worn during all maintenance and repair. •... - Page 12 Maintenance and Repair 3. Press wire form at the bottom of the Filter Bag. 7. Press wire and insert new Filter Bag into hole. 8. Ensure seals are installed correctly and properly sealed when reassembling the Main Housing. 4. Separate filter from hole by lifting up on the Filter V-Belt Replacement and Tensioning Bag.
- Page 13 Maintenance and Repair 2. Loosen the two bolts (labeled “B”) and remove Belt 5. Ensure pulleys are aligned after tensioning. If they Guard. are not aligned, release the belt tension, loosen the Engine Pulley set screws and align the pulleys. Check alignment after tensioning the V-Belt.
-
Page 14: Parts
Parts Parts Main Assembly Diagram (LazerVac 550) 3A5577C... -
Page 15: Main Assembly Parts (Lazervac 550)
Parts Main Assembly Parts (LazerVac 550) Part Number Description see page 17 Lid and Vacuum Release Plunger 17X196 Main Body Seal 17X197 Main Body Seal Ring 17X198 Filter Housing/Main Body see page 18 Filter Bag Assembly 17X199 Coupler Hose see page 19 Filter Housing Assembly 17X200 Main Frame... -
Page 16: Accessories Diagram (Lazervac 550)
Parts Accessories Diagram (LazerVac 550) Accessories Parts List (LazerVac 550) Part Number Description 17X156 Long Vacuum Hose, Standard, 2” (includes item 19) 17X704 Long Vacuum Hose, Heavy Duty, High Temp, 2” 17X158 Vacuum Extension (set of 2) 17X162 Vacuum Large Brush 17X161 Vacuum Small Brush 17X160... -
Page 17: Lid And Vacuum Release Assembly Diagram (Lazervac 550)
Parts Lid and Vacuum Release Assembly Diagram (LazerVac 550) Lid and Vacuum Release Assembly Parts List (LazerVac 550) Part Number Description 17X220 Vacuum Release Handle Assembly 17X227 Lower Lid 17X168 1/4-20 Acorn Nut 17W228 1/4” Lock Washer 17X174 1/4-20 Coupling Nut 17W259 1/4-20 Hex Nut 17X233... -
Page 18: Filter Bag Assembly Diagram (Lazervac 550)
Parts Filter Bag Assembly Diagram (LazerVac 550) Filter Bag Assembly Parts List (LazerVac 550) Part Number Description 17X235 Filter Funnel Base 17X236 Filter Seal 17X237 Filter Base Plate 17X238 Filter Bag (set of 7) 17X244 Wire Net and Spring Kit 3A5577C... -
Page 19: Air Filter Assembly Diagram (Lazervac 550)
Parts Air Filter Assembly Diagram (LazerVac 550) Air Filter Assembly Parts List (LazerVac 550) Part Number Description 17X245 Filter Main Casing 17X246 Filter Casing Lid 17Y254 Air Filter, set of 2 17X248 Relief Valve 3A5577C... -
Page 20: Cyclone 32 Assembly And Accessories Diagram
Parts Cyclone 32 Assembly and Accessories Diagram 3A5577C... -
Page 21: Cyclone 32 Assembly And Accessories Parts List
Parts Cyclone 32 Assembly and Accessories Parts List Part Number Description 17X206 Lid Funnel 17X209 Lid Base 17X196 Cyclone Ring, Metal 17X197 Cyclone Seal, Rubber 17X215 Dust Bag Holder 17X216 Dust Bag (35” x 47”) (set of 20) 17X217 Separator Main Frame 17X693 Short Vacuum Hose, Standard 2”... -
Page 22: Technical Data
Technical Data Technical Data LazerVac 550 (25M860), 13 HP Gasoline Air Flow (full throttle, without hose) - 295 cfm (501 m /hour) Air Flow (full throttle, with 2” x 30’ hose, no Y-Connector) - 216 cfm (367 m /hour) Vacuum Pressure (no flow) - 148” H 0 (276 mm Hg, 0.37 bar) Maximum Air Power (without hose) - 2045 Air-Watts Filtration - 99.3% at 0.3 μm particle size... -
Page 23: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective. - Page 24 Original instructions. This manual contains English. MM 3A5577 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2018, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
