Page 3 ASSEMBLY INSTRUCTIONS FOR VORTEX AIR HOCKEY TABLE Please retain this information for future reference. Two adults are needed to assemble the table. 1. Find a clear level area on which to assemble your air hockey table. It is best to flatten out the delivery carton &...
Page 4 4. Attach the leg panels P4 to the exposed side of the legs P2 using the bolts H2 & flat washers H5 as shown below. 5. The following steps will require the use of the glue (A4) provided to help secure the parts together. Apply the glue behind the wooden blocks on the lower side panel P6 &...
Page 5 6. Attach the previously-made leg assemblies to the main section of the table using the bolts H3 & flat washers H6 as shown below. Attach the leg base trim P11 to the legs using screws H7. 7. Screw one leg leveller P10 into the bottom of each leg as shown below. 8.
Page 6 9. Attach the electronic scorer P12 using the screws H8 as shown below. Then attach the end puck collection units P13 using screws H7. You are now ready to play! For sales & service please contact Mightymast Leisure Ltd 58 Bentwaters Park, Rendlesham Woodbridge, Suffolk. IP12 2TW.
