Summary of Contents for BIOS Diagnostics 33302
- Page 1 Forehead Thermometer Thermomètre frontal 3 sec. measurement Mesure en 3 secondes 3 sec. Fever alarm Signal de fièvre Illuminated display Écran lumineux 12 Memories 12 Mémoires Signal Tone Signal sonore Celsius - Fahrenheit...
- Page 2 seconds secondes Realtime Technology Technologie en temps réel Forehead Thermometer Instruction Manual Thermomètre frontal Mode d’emploi...
- Page 3 Please read these instructions carefully before using the instrument and keep them in a safe place. The Bios Diagnostics Forehead Thermometer is a high quality product incorporating the latest technology and tested in accordance with international standards. With its unique...
-
Page 4: Table Of Contents
Table of Contents 1. The Advantages of your Forehead Thermometer 2. Important Safety Instructions 3. Product Description 4. How the Forehead Thermometer Measures Body Temperature 5. Control Displays and Symbols 6. Directions for Use 7. Changing from Fahrenheit to Celsius and vice-versa 8. -
Page 5: The Advantages Of Your Forehead Thermometer
1. The Advantages of your Forehead Thermometer Measurement in 3 seconds The innovative infrared technology allows measurement of body temperature in only 3 seconds. Accurate and reliable Due to the unique probe assembly construction, the advanced infrared sensor and the complete calibration process, this unit can offer a temperature measurement comparable to one taken from the oral site with a regular digital thermometer. -
Page 6: Important Safety Instructions
2. Important Safety Instructions • Never use the thermometer for purposes other than those it has been intended for. Please follow the general safety precautions when using on children. • Never immerse the thermometer into water or other liquids (not waterproof). For cleaning, please follow the instructions in the «Cleaning and Storage» section. -
Page 7: How The Forehead Thermometer Measures Body Temperature
4. How the Thermometer Measures Body Temperature The thermometer measures infrared energy radiated from the skin of the temporal area and surrounding tissue. This energy is collected through the lens and converted to a temperature value. The measured reading obtained 1 cm above the tail of the eyebrow can ensure the most accurate temperature. -
Page 8: Directions For Use
6. Directions for Use 1. Press the O/I button. The LCD is activated to show all segments for 2 seconds. 2. The last measurement reading will be shown on the display automatically for 3 seconds with the «M» icon. 3. When the °C or °F icon is flashing, a beep sound is heard and the thermometer is ready for measurement. -
Page 9: Changing From Fahrenheit To Celsius And Vice-Versa
• Do not take a measurement while or immediately after nursing a baby. • Do not use the forehead thermometer in high humidity environments. • Patients should not drink, eat, or exercise before/while taking the measurement. • Before placing the thermometer probe onto the measure- ment area, remove dirt, hair, or sweat. • Do not move the measurement device before hearing the termination beep. • Use an alcohol swab to carefully clean the probe and wait for 15 minutes before taking a measurement on another patient. • Always take the temperature in the same location, since the temperature readings may vary from different locations. -
Page 10: Error Messages
8. Error Messages Display / Display Meaning Possible cause and Problem fault remedy Measured Displays «H» when temperature is measured temperature too high is higher than 42.2 °C (108.0 °F). Measured Displays «L» when temperature is measured temperature too low is lower than 34.0 °C (93.2 °F). Ambient Displays «H» in temperature is conjunction with the too high... -
Page 11: How To Recall 12 Readings In Memory Mode
9. How to Recall 12 Readings in Memory Mode The thermometer can recall the last 12 readings. To recall please follow the sequence below. Display Display Meaning Description Recall Mode Press the START button to enter Recall Mode when power is off.The memory icon «M»... -
Page 12: Replacing The Battery
Take care not to scratch the surface of the LCD. Remove the battery from the instrument if it is not required for extended periods of time in order to avoid damage to the thermometer resulting from a leaking battery. 11. Replacing the Battery This thermometer is supplied with one lithium battery, type CR2032. Replace with a new CR2032 battery when the flashing battery symbol appears on the LCD display. -
Page 13: Guarantee
12. Guarantee The Forehead Thermometer is guaranteed to be free from defects in material and workmanship for the life of the original owner. The guarantee does not apply if the defect or malfunction is a result of user abuse, misuse, alteration, modification or damages in transit. -
Page 14: Technical Specifications
13. Technical Specifications According to the Medical Product User Act a biennial technical inspection is recommended for professional users. Type: Forehead Thermometer 33302 Measuring 34.0°C to 42.2°C (93.2°F to 108.0°F) Resolution: 0.1°C / °F Accuracy: Laboratory: ±0.2°C, 36.0°C ~ 39.0°C (±0.4°F, 96.8°F ~ 102.2°F) (Ambient Temperature: 16°C to 40°C, 60.8°F to 104°F ) Display: Liquid Cristal Display, 4 digits plus special icons Acoustic: a. The unit is turned ON and ready for the measurement: 1 short «bip»...
