Kurgo SKYBOX Installation & Care Manual

BASIC SETUP
1. Place bottom of U-shaped steel support brace into the bottom back of of the Skybox frame under the removable
liner, with the two ends facing up and toward the front at a 45º angle. (image 1)
2. Place ends of U-shape steel support through button holes at the top front of the Skybox frame, inside each of these holes is a
plastic tube which the ends of the U-shape steel support t into. (image 2 and 3)
3. Place the liner into the Skybox frame and fold edge over. You will nd three slits in the liner, one in the back that
the metal buckle for securing Skybox Tether (e) pulls through and one on each side for the Headrest Strap (a) to attach.
4. Place reversible Quilted Seat Pad in the bottom, on top of the liner.
1
INSTALLATION IN VEHICLE:
1. Buckle the seat belt where the booster seat will be installed.
Clip Headrest Strap (a) to Headrest Strap Clips (c) on
sides of Skybox frame ( g 4) and loop over the top of the
headrest. Use the Strap Adjuster (b) to select a suitable
height for your Skybox.
2. Wrap Seat back Strap (d) around the back of the seat and
clip buckles together. Pull strap to tighten. ( g 5)
3. Follow instructions on back ( g 6) to secure Skybox Tether
(e) once Fido is attached you are ready to roll.
INSTALLATION IN VEHICLE WITHOUT HEADREST:
1. Buckle the seat belt where the booster seat will be installed.
Clip Headrest Strap (a) to Headrest Strap Clips (c) on sides
of Skybox frame ( g 4) and loop over the top of the seat.
Extend the length of the Headrest Strap (a) so the bottom
of Skybox Booster Seat rests on seat.
2. Wrap Seat back Strap (d) around the back of the seat and
clip buckles together. Pull strap to tighten. ( g 5)
3. Follow instructions on back ( g 6) to secure Skybox Tether
(e) once Fido is attached you are ready to roll.
Check with vehicle manufacturer
for air bag guidelines.
Installation & care
2
A D-ring / Anneau en D
B Leash hook / Laisse
C Nested Buckles™ / Niché Buckles
D Lower Straps / Sangles inférieures
E Padded Chest Plate / Plastron
F Upper Straps / Sangles supérieures
4
3
KEY: KEY:
Headrest Strap Headrest Strap
Headrest Strap Adjuster Headrest Strap Adjuster
Headrest Strap Clips Headrest Strap Clips
Seat Back Strap Seat Back Strap
Harness Tether Harness Tether
5
5-11
