  • Page 1 USER’S MANUAL BPL48V75ART2U K01-0000152-02...
  • Page 2 INTRODUCTION Overview The Extended Battery Module (EBM) is designed for various CyberPower UPS systems and can be used in either rack or tower installation. The heavy gauge power cord has a plug-n-play DC connector for easy installation. When combining with UPS, the EBM provides extended runtime with a 48V DC external connection.

  • Page 3: Basic Configuration

    BASIC CONFIGURATION On-board User-replaceable Fuse Cover Extended Battery Module Connecter Plug Additional Extended Battery Module Connecter Socket AC Input Circuit Breaker AC Inlet: AC power connectivity to wall receptacle. AC Outlet: This outlet connects to the AC inlet of additional Extended Battery Modules. INSTALLATION Rack-mounting Installation for 4-post Rack Release the two (2) screws from the unit.
  • Page 4 INSTALLATION (cont.) Rack-mounting Installation for 4-post Rack (cont.) Screw the hanging rails to the rack with Lift the unit upon the hanging rails and slide eight (8) M5 pan head screws and plastic the unit into the rack. Affix the unit to the washers.

  • Page 5: Basic Operation

    INSTALLATION (cont.) Tower Installation for PR5000LCDRTXL5U/ PR6000LCDRTXL5U/ PR5000ELCDRTXL5U/ PR6000ELCDRTXL5U Step 1. Stand the UPS and the Extended Battery Module(s). Step 2. Mounting two stabilizer brackets (supplied with UPS) to outside of UPS and Extended Battery Module(s). Step 3. Affix the rubber feet to the bottom of the Extended Battery Module.
  • Page 6 BASIC OPERATION (cont.) Connect the Extended Battery Module to your UPS by plugging the Extended Battery Module connector plug into the connector socket on the rear panel of the UPS. Ensure the color coded connector plug lines up correctly with the colors in the UPS socket, such as red to red, black to black and green to green.

  • Page 7: Troubleshooting

    12 hours. does not work. Batteries are degraded. Contact CyberPower about replacement batteries. The fuse blew. Contact CyberPower for repair. Additional troubleshooting information can be found at www.cyberpower.com. TECHNICAL SPECIFICATIONS Model BPL48V75ART2U AC Input Voltage Range 100Vac – 240Vac DC Output...
  • Page 8 LIMITED WARRANTY AND CONNECTED EQUIPMENT GUARANTEE Read the following terms and conditions carefully before using the CyberPower BPL48V75ART2U (the “Product”). By using the Product you consent to be bound by and become a party to the terms and conditions of this Limited Warranty and Connected Equipment Guarantee (together referred to as this “Warranty”).
  • Page 9 What will we do to correct problems? CyberPower will inspect and examine the Product. If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required).
  • Page 10 1ms has occurred, the occurrence will be deemed outside the rated capabilities of the Product and the Limited Warranty is void. CyberPower Does Not Cover or Undertake Any Liability in Any Event for Any of the Following: Loss of or damage to data, records, or software or the restoration of data or records, or the reinstallation of software.

  • Page 11: Regulatory Compliance

    Risk Activities"). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High Risk Activities or with Aquariums. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF THE PRODUCT.
  • Page 12 Visit CyberPower at www.cyberpower.com to get more information. Entire contents copyright © 2018 Cyber Power Systems, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited. CyberPower is a registered trademark and brand of Cyber Power Systems (USA), Inc.
