POSITIP 8000
Operating Instructions
Turning
Digital Readout
English (en)
03/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POSITIP 8000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HEIDENHAIN POSITIP 8000

Summary of Contents for HEIDENHAIN POSITIP 8000

  • Page 1 POSITIP 8000 Operating Instructions Turning Digital Readout English (en) 03/2020...

  • Page 2: Table Of Contents

    13 Programming..........................201 14 File management..........................213 15 Settings............................221 16 Servicing and maintenance......................277 17 What to do if ..........................287 18 Removal and disposal........................293 19 Specifications..........................295 20 Index...............................302 21 List of figures..........................305 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 3 Intended use............................28 Improper use............................28 Personnel qualification........................29 Obligations of the operating company....................29 General safety precautions......................... 30 2.7 .1 Symbols on the product......................30 2.7 .2 Electrical safety precautions....................31 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 4 Mounting on Multi-Pos holder....................44 Installation............................45 Overview............................... 46 General information..........................46 Device overview........................... 47 Connecting encoders........................... 50 Wiring switching inputs and outputs....................51 Connecting input devices........................54 Connecting a network peripheral.......................54 Connecting the line voltage........................55 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 5 Position display functions......................80 6.10 Status bar............................. 82 6.10.1 Operating elements of the status bar..................82 6.10.2 Adjusting settings in the quick access menu................84 6.10.3 Stopwatch..........................85 6.10.4 Calculator..........................85 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 6 6.11 OEM bar..............................86 6.11.1 Operating elements of the OEM bar..................87 6.11.2 Calling functions of the OEM bar....................87 6.12 Messages and audio feedback......................88 6.12.1 Messages..........................88 6.12.2 Wizard............................89 6.12.3 Audio feedback.........................90 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 7 Backing up and restoring OEM settings................129 7 .9.7 Configuring the unit for screenshots..................130 7.10 Backing up data..........................131 7 .10.1 Back up settings........................131 7 .10.2 Back up user files........................132 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 8 9.4.3 Finding the preset........................161 Roughing the outside contour......................161 Turning the recess..........................164 Turning the chamfer...........................165 Finishing the outside contour......................165 Machining threads..........................168 9.9.1 Defining threads........................169 9.9.2 Thread cutting........................170 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 9 Machining cycle........................183 11.4 Executing blocks..........................186 11.5 Using the simulation window......................187 11.5.1 Depiction as contour view.....................188 11.6 Working with the positioning aid....................189 11.7 Applying the Scaling factor......................189 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 10 Closing a program........................211 13.5.3 Saving a program........................211 13.5.4 Saving a program under a new name................... 212 13.5.5 Saving a program automatically.....................212 13.5.6 Deleting a program........................ 212 13.6 Editing program blocks........................212 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 11 Contents 14 File management..........................213 14.1 Overview............................. 214 14.2 File types.............................215 14.3 Managing folders and files....................... 215 14.4 Viewing files............................218 14.5 Exporting files............................ 218 14.6 Importing files............................ 219 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 12 Configuring M functions......................242 15.5.10 Special settings........................243 15.5.11 Thread cutting........................244 15.5.12 <Axis name> (settings of the axis)..................244 15.5.13 Encoder..........................247 15.5.14 Reference marks (Encoder)....................250 15.5.15 Reference point displacement....................251 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 13 15.6.14 Settings (OEM area)......................273 15.6.15 Program execution......................... 273 15.6.16 Configuring M functions......................274 15.6.17 Text database......................... 274 15.6.18 Messages..........................275 15.6.19 Back up and restore (OEM area)................... 275 15.6.20 Documentation........................276 15.6.21 Software options........................276 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 14 System or power failure........................288 17 .2.1 Restoring the firmware......................288 17 .2.2 Restore settings........................289 17.3 Malfunctions............................289 17 .3.1 Troubleshooting........................289 18 Removal and disposal........................293 18.1 Overview............................. 294 18.2 Removal...............................294 18.3 Disposal............................... 294 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 15 Product dimensions with Single-Pos stand................300 19.3.2 Product dimensions with Duo-Pos stand................300 19.3.3 Product dimensions with Multi-Pos stand................301 19.3.4 Product dimensions with Multi-Pos holder................301 20 Index...............................302 21 List of figures..........................305 HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...

  • Page 17: Fundamentals

    Fundamentals...
  • Page 18 ID number Demo software for the product POSITIP 8000 Demo is software you can install on a computer regardless of the device. POSITIP 8000 Demo helps you to become familiar with, try out or present the functions of the device.
  • Page 19 If the ID numbers and indexes do not match, so that the documentation is not valid, you will find the current documentation for the product at www.heidenhain.de. HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 20 Have you found any errors or would you like to suggest changes? We continuously strive to improve our documentation for you. Please help us by sending your suggestions to the following e-mail address: userdoc@heidenhain.de HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 21 These instructions must be read and observed by every person who performs any of the following tasks: Mounting Installation Commissioning and configuration Operation Programming Service, cleaning and maintenance Troubleshooting Removal and disposal HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 22 ... items supplied with the product ... accessories for the product ✓ ✓ ... correct mounting of the product 4 "Mounting" ✓ ✓ ... correct installation of the product 5 "Installation" HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 23 ✓ ✓ ✓ 19 "Specifications" ... product dimensions and mating dimensions (drawings) This chapter enables accessing the content of these ✓ ✓ ✓ 20 "Index" instructions according to specific topics. HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 24 The behavior of the functions depends on the configurable machine settings The book symbol represents a cross reference to external documentation, e.g. the documentation of your machine tool builder or other supplier. HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
  • Page 25 Identifies an item of a list Example: TTL interface EnDat interface Bold Identifies menus, displays and buttons Example: Tap Shut down The operating system shuts down Turn the power switch off HEIDENHAIN | POSITIP 8000 | Operating Instructions Turning | 03/2020...
