Technical Specifications
6 ... 30VDC or
Power supply
2x 1.5V AAA batteries
typ. 87mW, max. 119mW
Power consumption
max. 119mW
Power loss
Battery lifetime
up to 2 years
Loxone Air:
Interface
868MHz (SRD Band Europe),
4 channels available
915MHz (ISM Band Region 2),
10 channels available
max. Power 3.16mW
Ambient temperature
external power supply:
-20 ... 70°C / -4 ... 158°F
battery powered:
-20 ... 54°C / -4...129°F
Humidity
max. 95% r.H. (non condensing)
5 touch points, capacitive
Touch points
touch detection
Click feedback
Yes
Temperature detection range
-40 ... 125°C / -40 ... 257°F
+/- 0.5°C / 0.9°F
Humidity detection range
0 ... 100% r.H. +/- 2%
(non condensing)
Orientation light
only possible with power supply
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Touch
Pure
Air
Part No: 100399 (White)
Part No: 100400 (Anthracite)
