Home
PBXware
SERVERware
TELCOware
SIPmon
SIPProt
Desktop & Mobile
BRM
UADs
Appliances
EOL
From Bicom Systems Wiki
Contents
1 Introduction - How to use the Linksys SPA-962 with PBXware
2 Registering Linksys SPA-962
2.1 Requirements
2.2 Manual Configuration
2.3 Auto Provisioning
3 Paging
4 Glossary
Introduction - How to use the Linksys SPA-
962 with PBXware
This "How to" is written as a general guide on how to use the Linksys SPA-962 with PBXware
using 4.1.12(a) Linksys SPA-962 firmware. It covers the most common tasks required to have
your Linksys SPA-962 working efficiently.

Advertisement

loading

Related Manuals for Linksys SPA-962

Summary of Contents for Linksys SPA-962

  • Page 1 Introduction - How to use the Linksys SPA- 962 with PBXware This "How to" is written as a general guide on how to use the Linksys SPA-962 with PBXware using 4.1.12(a) Linksys SPA-962 firmware. It covers the most common tasks required to have...
  • Page 2 - The Linksys SPA-962 "Dial Plan" field value needs to be changed using the web interface. STEP ONE: Linksys SPA-962 Web Interface. 1. Open a new browser window and enter the IP address in order to access the Linksys SPA-962 administration interface.

  • Page 3: Manual Configuration

    4. Navigate down to the "Dial Plan" group. Clear "Dial Plan" field, then copy and paste the following value. (*x.|**x.|*xx|[3469]11|0|00|[2-9]xxxxxx|1xxx[2-9]xxxxxx|xxxxxxxxxxxx.) 5. Click on the "Submit All Changes" button. The Linksys SPA-962 will reboot for changes to take effect. Manual Configuration UAD Settings STEP ONE: PBXware IP address.
  • Page 4 2. Hit "Enter" on your keyboard. 3. Login to PBXware with your e-mail address and password. STEP THREE: UAD status. 1. Make sure the UAD is enabled. To check the UAD status, navigate to "Settings:UAD", and click on the "edit" icon corresponding to "Linksys SPA-962".
  • Page 5 2. Make sure "Status" is set to "Active", "Auto provisioning" is set to "No" and "DHCP" is set to "Yes".
  • Page 6 3. Click on the "Save" button to save changes. Creating Extension STEP ONE: Add Extension. 1. Navigate to "Extensions". Click on "Add Extension". 2. The standard options window will be shown below.

  • Page 7: Required Fields

    3. Select Linksys SPA-962 from the "UAD" select box. 4. Select Location: "Local" or "Remote". Note: -"Local" is for all extensions registered on LAN. -"Remote" is for all extensions registered from remote networks, WAN, Internet etc. 5. Click on the "Next" button.

  • Page 8: Registering Phone

    Registering Phone STEP ONE: Electricity and Ethernet. - Your Linksys SPA-962 needs electricity, so plug the adapter into its jack and connect it to the electricity network. - Connect the ethernet port to a hub, router, or switch as access to LAN.
  • Page 9 1. Press the menu button. 2. On the display, navigate down to "Network" using the navigation button. 3. Press the "select" button. STEP THREE: Linksys SPA-962 Web Interface. Registering Phone 2. Hit "Enter" on your keyboard. STEP FOUR: Configuring Linksys SPA-962.

  • Page 10: Auto Provisioning

    The Secret of the extension as received in the e-mail associated with this extension. Example: 3dX3r5 an example with details filled in 4. Navigate to the bottom of the page, click on "Submit All Changes" button. The Linksys SPA- 962 will reboot for changes to take effect. OPTIONAL FIELDS: Display Name: Example: John Smith, Reception, Entrance Main, Agent One etc.
  • Page 11 2. Hit "Enter" on your keyboard. 3. Login to PBXware with your e-mail address and password. STEP THREE: UAD status. 1. Make sure the UAD is enabled. To check the UAD status, navigate to "Settings:UAD" and click on the "edit" icon corresponding to "Linksys SPA-962".
  • Page 12 2. Make sure "Status" is set to "active", "Auto provisioning" is set to "Yes" and "DHCP" is set to "Yes".
  • Page 13 3. Click on the "Save" button to save changes. Creating Extension STEP ONE: Add Extension. 1. Navigate to "Extensions". Click on "Add Extension". 2. The standard options window (below) will be shown.
  • Page 14 3. Select Linksys SPA-962 from the "UAD" select box. 4. Select Location: "Local" or "Remote". Note: -"Local" is for all extensions registered on LAN. -"Remote" is for all extensions registered from remote networks, WAN, Internet etc. 5. Click on the "Next" button.
  • Page 15 Registering Phone: One Extension STEP ONE: Electricity and Ethernet. - Your Linksys SPA-962 needs electricity, so plug the adapter into its jack and connect it to the electricity network. - Connect the ethernet port to a hub, router or switch to access LAN.
  • Page 16 3. Press the "Menu" button. Registering Phone: One Extension STEP THREE: Linksys SPA-962 Web Interface. 1. Open a new browser window and enter the IP address in order to access the Linksys SPA-962 administration interface. Example: http://192.168.1.101/ an example with IP address 2.
  • Page 17 3. Click on the Provisioning link. 4. Navigate down to the "Profile Rule" field, it must be set with TFTP server value. Example: 192.168.1.2/$MA.cfg an example with details filled in 5. Click on the "Phone" link. 6. Navigate down to "Line Key 1, 2, 3 and 4" and select values: - Line Key 1: Extension select: 1.
  • Page 18 7. Navigate to the bottom of the page, click on "Submit All Changes" button. The Linksys SPA- 962 will reboot for changes to take effect. - Conclusion: If everything is done as above described, you should have successfully registered the Linksys SPA-962 to PBXware. Dial *123 to verify registration.
  • Page 19 2. Navigate down to the "Auto Provisioning" group. - LAN IP: Enter your PBXware local (LAN) IP address. Example: 192.168.1.2 - WAN IP: Enter your PBXware wide (WAN) IP address. Example: 89.146.131.130 an example with details filled in 3. Click on the "Save" button. You'll be prompted to click on the "OK" button to restart the PBXware for changes to take effect.
  • Page 20 2. Select "Admin Login". 3. Select "Advanced". 4. Navigate to the "User" tab 5. Set "Auto Answer Page" to "Yes" . 6. Set "Send Audio To Speaker" to "Yes" . 7. Click on the 'Submit All Changes' button. NOTE: At the time, the paging option is set for all lines and works once the handset is picked up.
  • Page 21 - HUB = A common connection point for devices in a network. - IP Address = Internet Protocol address. - Local = A local area network (LAN) is a computer network covering a local area, like a home, office or small group of buildings such as a college. - LAN = Local Area Network.
