- Page 1 AP-IP User & Instalation Manual Instrukcja instalacji (DTR). Ropam Elektronik Tel. +48 12 272 39 71 Polanka 301 www.ropam.com.pl Document version : 1.0 32-400 Myślenice, Polska Faks +48 12 379 34 10 biuro@ropam.com.pl 2017-10-06...
- Page 2 - according to application. The device is a source of electromagnetic waves, so it may interfere with other radio devices in specific configurations. Ropam Elektronik is not responsible for any malfunction of the GSM network and any possible technical problems. WEEE LABELING Waste electrical and electronic equipment must not be disposed of with household waste.
-
Page 3: Table Of Contents
System support - applications for mobile devices................18 RopamOptima application ......................18 Start-up ............................18 Configuration ..........................21 System demo ..........................22 Wbudowany webserwer ........................ 23 System maintenance........................24 Technical parameters........................25 Version history..........................26 Information............................27 © 2017 Ropam Elektronik... - Page 4 General description. Page 01 © 2017 Ropam Elektronik...
-
Page 5: General Description
Thank you for choosing Ropam Elektronik products and solutions. We hope that our equipment will meet your requirements and will serve you reliably for years to come. Ropam Elektronik continues to innovate its products and solutions. With the update function products can be enriched with new features and keep up with the modern requirements for the protection of property systems and home automation. - Page 6 • It is necessary to maintain possible antistatic protection measures to protect electronic circuits on PCBs against electrostatic discharge ESD. • In order to meet the requirements of LVD and EMC, the following rules must be observed: power supply, installation, shielding - according to the application. © 2017 Ropam Elektronik...
-
Page 7: Description Of The Module
All connections and installation should be made while the motherboard power supply is off. Incorrect installation of the AP-IP module in the motherboard may cause damage to the devices. AP-IP is supported from: OptimaGSM v1.9, TPR-xx_OptimaGSM v1.3, OptimaGSM Manager 1.6. © 2017 Ropam Elektronik... - Page 8 • no light = lost communication with the control panel (+ possibly shines FAIL) • lights up = wired LAN (ETH) connector works correctly RJ45-Pwr GREEN • no light = no wired LAN communication RJ45-Tx/Rx YELLOW • blinks = signaling of Tx / Rx transmission © 2017 Ropam Elektronik...
-
Page 9: Assembly And Installation
In the case of the version in the housing for a DIN rail (- D9M), the housing should be opened by releasing the lateral hooks. Remove the control panel PCB, install AP-IP module, assemble the whole in reverse order and lead out the RJ12 / 4pin cable and the aerial FME wire. © 2017 Ropam Elektronik... - Page 10 For security reasons, the WPA2 password must be changed on the site unconditionally. 8. After configuring the control panel with the AP-IP module, connect the control panel and the AP-IP module with the 4pin / RJ12 cable: © 2017 Ropam Elektronik...
- Page 11 - identification and programming of the current configuration program, dedicated to the latest versions, - verification and possibly changes in functions, LogicProcessor scripts, - deleting and creating new users of the system (codes) and granting them access to IP. © 2017 Ropam Elektronik...
-
Page 12: Configuration
- Router Administration Panel (LuCI): TCP port 444 (https: //), - OptimaGSM Manager programming: TCP port 8882 Comments: Ports to the router panel and TCP / IP programming are not recommended to be shared outside the local network. Configuration: OptimaGSM Manager. AP-IP module configuration options. © 2017 Ropam Elektronik... - Page 13 The RTSP stream should be configured from the cameras / DVR. The RTSP path can be checked using VLC. In the case of freeze frames, the frequency of images downloading can not be higher than 1 for 5s. The AP-IP module settings window (configuration of access paths for IP cameras). © 2017 Ropam Elektronik...
- Page 14 The transmission quality for the auxiliary channel should be smaller than the main stream - it will ensure correct compression of the downloaded images. Recommended not greater than D1. In order for the path to the camera to be interpreted correctly, the whole address should be taken in quotation marks! Example: © 2017 Ropam Elektronik...
-
Page 15: Configuration And Status Control: Sms
AP-IP default settings (ETH: DHC client, #### apipdefault WLAN: Access Point, webserver https://192.168.10.1) Comments: - default WebSerwer for Wifi connection - AccesPoint is: https: 192.168.10.1 - SMS commands require authorization with the main code. © 2017 Ropam Elektronik... -
Page 16: System Configuration: Tcp / Ip Ap-Ip Module
- knowledge: ID of the control panel, TCP / IP key, communication password with the PC (or file with the control panel configuration), - TCP / IP remote programming option selected The LAN / WiFi network parameters can be read out from the touch panel - user settings -> Internet module (TPR-1x, TPR-2x, TPR-4): © 2017 Ropam Elektronik... - Page 17 - ETH mode of operation: DHCP client, - TCP / IP key = ID of the control panel (see sticker) - communication password with PC: 111111 The above settings allow programming through the TCP / IP of the factory OptimaGSM control panel! © 2017 Ropam Elektronik...
-
Page 18: Advanced Configuration Of The Router
- in the installer and ftp zones with application notes there are examples of configuration changes, e.g. permanent IP for ETH, changing the addressing of the ETH network, WLAN, change of ports for WebSewrer and LuCI. © 2017 Ropam Elektronik... -
Page 19: Providing A Fixed Ip Address
(when there are problems with the assignment of addressing via DHCP). To give a permanent IP for the required interface: Log in to the exchange via the browser: Go to the "Ustawienia (Settings)" tab: Click the router icon: © 2017 Ropam Elektronik... - Page 20 Configuration. Page 17 And choose interface menu to change the IP address: Editing a given interface launches the address change menu: After correct configuration of addresses, you should save your swaps by clicking "Save and apply". © 2017 Ropam Elektronik...
-
Page 21: System Support - Applications For Mobile Devices
OptimaGSM control panel v2.3 or higher. Communication module AP-IP version v1.4 or higher. Phone or tablet with Android, Apple iOS, Windows10 Mobile. Start-up After installation, the RopamOptima application should be started by tapping on the application icon. © 2017 Ropam Elektronik... - Page 22 For correct login it is necessary to define and select the object with which we want to connect (there may be many of them). Select the "Change" button. A screen with a list of objects will appear: © 2017 Ropam Elektronik...
- Page 23 Example configuration without RopamBridge (logging in to a local network or using a fixed IP, external domain / IP address). The values entered in the fields are checked and in the case when the entered value is incorrect, the text in the field will be highlighted in red. © 2017 Ropam Elektronik...
-
Page 24: Configuration
(tap) and longer holding the finger on the object. Then the object window appears with the previously entered data. Settings for objects can be transferred to another device using settings export / import. © 2017 Ropam Elektronik... -
Page 25: System Demo
The user code is a four-character code for the OptimaGSM central with the permission to control via SMS / www. System demo The Ropam Elektronik company allows you to connect to the "Demo" object using the RopamOptima application, which allows you to easily find out about the possibilities of the system and check its functionality. -
Page 26: Wbudowany Webserwer
- support for up to 8 users at the same time Requirements: OptimaGSM control panel v2.1 or higher. Communication module AP-IP version v1.3 or higher. A computer, phone or tablet with Android, Apple iOS, Windows10 Mobile with a web browser that supports HTML 5. © 2017 Ropam Elektronik... -
Page 27: System Maintenance
The device does not require any special maintenance. During periodic technical inspections, it is necessary to check the condition of screw joints, emergency power supply status, clean the PCB with compressed air. The system should be periodically tested for proper operation and communication. © 2017 Ropam Elektronik... -
Page 28: Technical Parameters
Wifi in 802.11 b / g / n, 2.4 GHz, 150 Mbs, 21dB max. Transmit power, modem on the housing (0 dBi) environmental class: II, temp.: 10 ° C ... + 55 ° C Working conditions RH: 20% ... 90%, no condensation Dimensions 54x56x30 WxHxD [mm] © 2017 Ropam Elektronik... -
Page 29: Version History
- cooperation with IP cameras and DVR recorders, capturing RTSP stream (4) for creating photos for MMS (GPRS) or e-mail attachments (IP, internet) 2016.08.05 * new features: - support for the RopamOptima application on mobile devices 2016.10.06 * new features: - Modbus protocol support © 2017 Ropam Elektronik... -
Page 30: Information
Page 27 Information. The Ropam Elektronik company is the sole owner of copyrights to the materials contained in the documentation, catalog and website, in particular for photos, descriptions, translations, graphic form, presentation. Any copying of information or technical materials found in catalogs, on websites or otherwise provided by Ropam Elektronik requires written permission.
