Page 2
WEEE Directive (Directive 2002/96/EC) and is effective only with EU. The power-supply (NEO-PS) cooperates with the 12V DC sealed lead- acid battery (SLA, VRL). After the operating period ends, the power- supply shall not be discarded but recycled according to valid regulations (of EU directive no.
Page 3
- adjustable JPG pictures quality (sending four pictures in one message possible), - saving pictures on SD card function 'control panel” - NEO-PS & TPR-1: controlled with: TouchPanel (keypad) SMS, input, - as above & PSR-RF: controlled with: radio keyfob - NEO-PS: controlled with: SMS, input...
Page 4
Installation and operating manual: NEO/NEO-PS v.1.4S EN 2. PURPOSE The alarm system build on the basis of NEO/NEO-PS+ alarm controls panels, TPR-1 touch panel and other additional devices are ideal for housing properties and small commercial objects. A modern design, checked technology of a touch panel with an effective colourful LCD screen is excellent for most interiors and rooms.
Page 5
+BAT/+AKU (red) = '+' battery +BAT- -BAT/-AKU (black)= '-' battery (battery connector and PSRM module only in NEO-PS version) I7, I8 input polarization configuration jumpers (mounted - GND control active, JI7, JI8 removed control +12V (+u)) DO1...DO8...
Page 6
3.2.6 PSR-RF: THE BUFFERED POWER SUPPLY MODULE WITH TWO CHANNEL RADIO CONTROLLER The extended PSR version with built in two channel radio controller for the remote control of NEO (utilizing the control panel function). PSR-RF as an independent device can functionally replace any two channel radio link and a buffered 13.8V DC/1.3A power supply.
Page 7
4.2. CONNECTING THE VOICE SYNTHETIZER OR AUDIO MODULE. The NEO/NEO-PS+ module has a VSR socket intended for connecting the VSR-2, VSR-1 and the AMR-1 audio or other (e.g. utilized in CCTV) voice synthesizer modules, provisioned for listening in on the object.
Page 8
Installation and operating manual: NEO/NEO-PS v.1.4S EN 4.3. DEVICE CONNECTION TO INPUTS NEO/NEO-PS+ can operate with many types of input polarities. It can operate with any of the following: - detectors with outputs: NC (normally closed), NO (normally open), - alarm outputs: relay (RELAY zero potential contacts) - open collector (OC, BELL –...
Page 9
(the jumper JI7 or JI8 isn't installed) 4.4. DEVICE CONNECTION TO OUTPUTS. The NEO/NEO-PS+ module has got outputs for control and signaling the operation status. - O1, O2: in the active state we can connect (NO) or disconnect (NC) +12V power supply (transistor...
Page 11
The PARTNER GSM software is intended for operation on PC class computers running under the WINDOWS 9X/Me/2000/XP/VISTA operating system. Communication between PARTNER GSM and NEO is accomplished via: the RS232 port or the USB (1.1, 2.0) port utilizing communication cables with a built in RS- 232-RS232-TTL or a USB-RS232-TTL converter.
Page 13
5.2.2 REMOTE CONFIGURATION VIA MODEM CONNECTION (CSD) In the local connection mode for NEO/4.0 PS+ module (via RS232 – see: Local Configuration), it is possible to establish a modem connection with another module. In order to establish a modem connection, follow these steps: 1.
Page 15
• file on the local PC computer. 6.2.1 PHONE NUMBERS The NEO/NEO-PS module can signal four telephone numbers. The numbers should be entered in the international format. e.g. mobile number: +48555666777, fixed phone number: +48125556677 6.2.2 SMS CENTER The SMS center number should be chosen from the operators list bookmark (the number will be displayed automatically) or the field edited manually.
Page 18
(the default setting is 0s). Min/max time = 1/360min (this option is used for limiting the number of messages and when using the NEO/NEO-PS as an alarm control panel; it enables actual control of the armed mode through the SMS messages).
Page 19
The column enables creating “night” zone of chosen inputs. Inputs marked in the columned will be in armed mode after setting night arm. REMARKS: From version v3.0 software NEO has got changes that adjust its functions to its operation as an alarm central with GSM communication. Basic changes in the tap: inputs.
Page 23
6.5 OPTIONS bookmark Options: Options 1, Options 2 (changed on the side belt) permit configuration of:: the transmission test • power supply control DC and AC (only NEO-PS) • counters limiting quantity and signaling duration times (costs) • time duration of: connections, input delays, CLIP, waiting for SMS message sending •...
Page 24
• entered in the bookmark. NO AC SUPPLY – enter the SMS message content corresponding to the decay of AC voltage (NEO- • PS only) in the tab. The time of signalization delay is configured in the DELAY [min] tab (in 5s –...
Page 29
SMS messages is tested in the SMS center. 6.7 UPDATE (bookmark) The modern solutions deployed in NEO, the processor system with the software in the FLASH memory, permit software updating, often containing new functions. Downloading new FIRMWARE via the module RS232TTL port, is possible without the necessity of uninstalling from the object.
Page 31
GSM messages. 6.8 EVENTS bookmark The NEO real time clock enables writing to the module event memory: input entry violations, functions, tests etc. The memory can register up to 1000 events taking place recently in such a way, that the oldest information is overwritten successively.
Page 34
Installation and operating manual: NEO/NEO-PS v.1.4S EN 6.9 FGR-4 MMS (bookmark) FGR-4 module is a device dedicated to work with NEO/NEO-PS modules. It enables conversion of four VIDEO signals (e.g. from video cameras, video entryphones, CCTV system) into JPG pictures and their preparation before transmitting them via MMS/E-MAIL messages (GPRS transmission).
Page 42
8. MODULE OPERATION SATUS SIGNALING The NEO module is equipped with an optical status signaling system. Four LED diodes mounted on the module board display the operation status of: signaling, communication with PC, software update. Color...
