TK Max Mix Assembly And Parts Manual page 5

8. Place the rubber gasket to the upper drum
making sure the holes align in both drum
halves.
9. Place the upper drum half on the lower
half, making sure the mounting holes are
clear to install the M6 x 16 mm screws into
each mounting hole, secure each screw
with elastic washers and hex flange nut.
10. Use the M8 x 16 hex bolt, washer & nut to
secure each mixer drum half and tight the
bolts.
11. Final Product.
5
