Changhong CHiQ
User Guide
CH7903-UC
Water Leak Sensor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHiQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Changhong Electric CHiQ

  • Page 1 Changhong CHiQ User Guide CH7903-UC Water Leak Sensor...
  • Page 2: Table Of Contents

    What’s in The Box ················································· 3 Set Up Water Leak Sensor ······································ 4 Sensor Placement ·············································· 8 Using CHiQ App with Water Leak Sensor ·················· 9 CHiQ Control ···················································· 12 Maintaining the Water Leak Sensor ························ 15 Specifications ················································· 17 Troubleshooting ··············································...
  • Page 3: Introduction

    Water Leak Sensor is widely used in water leak detection. There will have an alert when any of the three sets of probes were under the water. Download CHiQ App, add Water Leak Sensor to your smart home system, which will be able to monitor your home's security in real time.
  • Page 4 LED lights can show the current status of device. See the explanation below: FEATURE LIGHT BLINKING GREEN Connecting to cloud. FAST BLINKING GREEN Set up connection with devices. SLOW BLINKING GREEN Updating. FAST BLINKING RED Remove connection with devices. BLINKING RED AND GREEN ALTERNATELY Factory resetting.
  • Page 5: Features

    Features Real-time Status - Monitor the real-time state of water leak sensor via CHiQ App. Battery Status - Update battery level and send low battery alert. CHiQ Control - Trigger an action of certain CHiQ devices without internet. Automation - Set up rules for “If this then that” function.
  • Page 6: Set Up Water Leak Sensor

    Set Up Water Leak Sensor Follow the steps below to set up your Water Leak Sensor via CHiQ App. Step 1: Set up CHiQ App Get the CHiQ App from the Apple App Store or Google Play.
  • Page 7 Step 2: Log in or sign up with CHiQ account Open the App. Use your CHiQ account to log in. If you don’t have a CHiQ account, tap Sign up for an account and follow the steps to sign up an account.
  • Page 8 Name - Name Water Leak Sensor. b. Room - Choose a room for Water Leak Sensor. c. Favourite - Click “ ” icon to add/remove from Favourite. Tap the “Bind Device” to add the device to your CHiQ account.
  • Page 9 Step 4: Connect to the cloud Press the SET button once and your device will connect to the cloud automatically. Place the device to whenever you want to monitor. Note Make sure your hub is connected to internet.
  • Page 10: Sensor Placement

    Sensor Placement Located the water leak sensor in a location that may experience a water leak.
  • Page 11: Using Chiq App With Water Leak Sensor

    Using CHiQ App with Water Leak Sensor Device Alert Any of a set of probes are touched by water at the same time, an alert will be sent to your CHiQ account. Note Interval between two alerts is defaulted to be 5 minutes.
  • Page 12 Details You can customize the name, set the room, set the alert interval, enable/disable alert, add to/remove from favourite, check device history. a. Name - Name Water Leak Sensor. b. Room - Choose a room for Water Leak Sensor. c. Favourite - Click “...
  • Page 13 Automation Automation allows you to set up “If this then that” rules so the devices could act automatically. Tap “Smart” to switch to Smart screen and tap “Automation”. Tap “ ” to create an automation. To set an A u t o m a t io n , you will need to set a trigger time, local we a th e r co n d it i o n , or c hoo se a device with certain stage as triggere d co n d it io n .
  • Page 14: Chiq Control

    CHiQ Control CHiQ Control is our unique “device to device” control technology. Under CHiQ Control, the devices could be controlled without internet or Hub. Device which send out command is called controller (Master). Device which receive command and act accordingly is called responder (Receiver).
  • Page 15 Un-pairing Find the controller (Master) water leak sensor. Hold the set button for 10-15 seconds, the feature light will flash red quickly. Find the responder (Receiver) action device. Hold the power/ set button for 10- 15 seconds, the device will enter the un- pairing mode. The above two devices will unpair by themselves and the feature light stops flashing.
  • Page 16 CHiQ Control Diagram WATER LEAK WARNING WATER LEAK WARNING TURN ON TURN OFF TURN ON TURN ON UNPAIRED PAIRED...
  • Page 17: Maintaining The Water Leak Sensor

    Maintaining the Water Leak Sensor Firmware Update To ensure our customer have the best user experience, we highly recommend you could update our newest version firmware. Tap the “Water Leak Sensor” in App to go to its controls. Tap the “ ” icon at the top-right corner to go to details.
  • Page 18 Factory reset will erase all your settings and bring it back to default. After the factory reset, your device will be still in your CHiQ account. Hold the set button for 20-25 seconds until the feature light blinks red and green alternately.
  • Page 19: Specifications

    Specifications Voltage: 3V DC (2 - AAA battery) Environment: Operating temperature: 0°C~50°C (32°F~122°F) Operating humidity: ≤100%RH non-condensing...
  • Page 20: Troubleshooting

    Water leak sensor battery is dead. Please replace the battery. Device malfunction Please contact customer service. Notification has been turned off in CHiQ Please turn notification on in the setting LED blinking, no alert. App. page of CHiQ App.
  • Page 21: Customer Service & Warranty

    If you are unable to get your product working, please contact our customer service during business hours. US Live Tech Support: 1-408-9700349 M-F 9am - 5pm PST Email: crl@Changhong.us Changhong Research Labs Inc. 3945 Freedom Circle, Suite 320, Santa Clara, CA 95054 WARRANTY 2 Years Limited Electrical Warranty...
  • Page 22 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 23 FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. “To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.”...
