- Page 1 Changhong CHiQ User Guide CH7804-UC Motion Sensor...
-
Page 2: Table Of Contents
Contents Introduction · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1 Features ·... -
Page 3: Introduction
Introduction Motion Sensor is widely used in moving human body detection. Download CHiQ App, add Motion Sensor to your smart home system, which will be able to monitor your home's security in real time. LED lights can show the current status of device. See the explanation below: Red Once Alert. -
Page 4: Features
Features Real-time Status - Monitor the real-time state of movement via CHiQ App. Battery Status - Update battery level and send low battery alert. CHiQ Control - Trigger an action of certain CHiQ devices without internet. - Set up rules for “If this then that” function. Automation Product Requirements A CHiQ Hub. -
Page 5: Set Up Motion Sensor
Set Up Motion Sensor Follow the steps below to set up your Motion Sensor via CHiQ App. Step 1: Set up CHiQ App Get the CHiQ App from the Apple App Store or Google Play. - Page 6 Step 2: Log in or sign up with CHiQ account Open the App. Use your CHiQ account to log in. If you don’t have a CHiQ account, tap Sign up for an account and follow the steps to sign up an account.
- Page 7 Step 3: Add device to CHiQ App Tap the “ ” in CHiQ App. Scan the QR Code on the device. You can customize the name, set the room, add to/remove from favourite. a. Name - Name Motion Sensor. b. Room - Choose a room for Motion Sensor.
- Page 8 Step 4: Connect to the cloud Press the SET button once and your device will connect to the cloud automatically. Note Make sure you hub is connected to internet. Internet Cloud SET BUTTON...
-
Page 9: Installation
Installation Recommended Installation CEILING Installation Height: 3-4m Diameter: 6-8m... - Page 10 Ceiling and Wall Installation Please use the screws to stick the plate to wherever you want to monitor. Please connect the sensor to the plate. Note Please add motion sensor to CHiQ App before you install it. CEILING WALL...
- Page 11 Using CHiQ App with Motion Sensor Device Alert A movement is detected, an alert will send to your CHiQ account. Note Interval between two alerts will be 1 minute. Device will not alert twice if movement is under continuously detection in 30 minutes.
-
Page 12: Using Chiq App With Motion Sensor
Using CHiQ App with Motion Sensor Details You can customize the name, set the room, add to/remove from favourite, check device history. a. Name - Name Motion Sensor. b. Room - Choose a room for Motion Sensor. - Click “ ”... - Page 13 Automation Automation allows you to set up “If This Then That” rules so the devices could act automatically. Tap “Smart” to switch to Smart screen and tap “Automation”. Tap “ ” to create an automation. To set an Automation, you will need to set a trigger time, local weather condition, or choose a device with certain stage as a triggered condition.
-
Page 14: Chiq Control
CHiQ Control CHiQ Control is our unique “device to device” control technology. Under CHiQ Control, the devices could be controlled without internet or Hub. Device which send out command is called controller (Master). Device which receive command and act accordingly is called responder (Receiver). - Page 15 Un-pairing Find the controller (Master) motion sensor. Hold the set button for 10-15 seconds, the light will flash red quickly. Find the responder (Receiver) action device. Hold the power/ set button for 10- 15 seconds, the device will enter the un- pairing mode. The above two devices will unpair by themselves and the light stops flashing.
- Page 16 CHiQ Control Diagram ALERT ALERT TURN OFF TURN ON TURN OFF TURN OFF PAIRED UNPAIRED...
-
Page 17: Maintaining The Motion Sensor
Maintaining the Motion Sensor Firmware Update To ensure our customer have the best user experience, we highly recommend you could update our newest version firmware. Tap the “Motion Sensor” in App to go to its controls. Tap the “ ” icon at the top-right corner to go to details. - Page 18 Factory Reset Factory reset will erase all your settings and bring it back to default. After the factory reset, your device will be still in your CHiQ account. Hold the set button for 20-25 seconds until the LED blinks red and green alternately. Factory reset will be done when the light stops flashing.
-
Page 19: Specifications
Specifications Voltage: 3V DC (1-CR123A battery) Detection Angle: 360° (Ceiling), 120° (Wall) Installation Height: 3m (Ceiling), 1.5m (Wall) Environment: Operating temperature: 0° C~50° C (32° F~122° F) Operating humidity: 0%~95% non- condensing... -
Page 20: Troubleshooting
Troubleshooting Problem Possible Reason Solution The most suitable temperature will be Temperature is too low or too high. Detection not work. 25℃(77° F). No alert or light. Motion sensor battery is dead. Please replace the battery. Please reconnect your hub to the Internet Hub is offline. - Page 21 If you are unable to get your product working, please contact our customer service during business hours. US Live Tech Support: 1-408-9700349 M-F 9am - 5pm PST Email: crl@Changhong.us Changhong Research Labs Inc. 3945 Freedom Circle, Suite 320, Santa Clara, CA 95054 WARRANTY 2 Years Limited Electrical Warranty...
-
Page 22: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 23 FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. “To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.”...
