ANTUMBRA
DIST
BUILDING INSTRUCTIONS
PCB V1.2

Advertisement

loading
Need help?

Need help?

Do you have a question about the DIST and is the answer not in the manual?

Questions and answers

Related Manuals for ANTUMBRA DIST

Summary of Contents for ANTUMBRA DIST

  • Page 1 ANTUMBRA DIST BUILDING INSTRUCTIONS PCB V1.2...
  • Page 2 01. BUILD NOTES Before you start building look through the build manual so that you’ll be familiar with the building process and you won’t run into any surprises!
  • Page 3 02. BUILD 00. Orient the PCB as seen on the left 01. Solder the two TL071s in place (oriented to the top) 02. Solder the two 1n5819 diodes Look out for their orientation! 03. Solder the single 470r resistor This is for the jack LEDs 04.
  • Page 4 02. BUILD 05. Solder the single 4.7k resistor 06. Solder the two 10k resistors 07. Solder the single 30k resistor 08. Solder the five 1M resistors 09. Solder the single 10pF capacitor...
  • Page 5 02. BUILD 10. Solder the three 1nF capacitors 11. Solder the single 10nF capacitor 12. Solder the single 47nF capacitor 13. Solder the three 100nF capacitors 14. Solder the two 1uF electrolytic capacitors Look out for their orientation! Their shape has to match up with the silkscreen.
  • Page 6 02. BUILD 15. Solder the two 10uF electrolytic capacitors Look out for their orientation! 16. Solder the two diodes for mode A. The type of these diodes are optional, you can use whatever SMD/TH diodes (even LEDs) you want, they all have different flavors, recommended is the 1n270 germanium diodes.
  • Page 7 02. BUILD 20. Solder the 1x3 pin header for the jack lights switch 21. Solder the two SMD LEDs Look out for their orientation! The marking should be as on the illustration. 22. Flip the board back! DO NOT SOLDER YET! 23.
  • Page 8 02. BUILD 25. Place the A100k pot 26. Place the A1M pot 27. Place the A10k pot Now put on the front panel and tighten the nuts on the jacks and pots. Align them in the holes as you like. Solder! You are done with building! Congratulations!
  • Page 9 DIST is designed by David Szebenyi under Antumbra. It is based on the MXR Distortion+ / Hexinverter Batteryacid v1.0 www.antumbra.eu Manual by David Szebenyi (www.aman.hu) 2019 • All rights reserved!
