- Page 1 ANTUMBRA DVCA BUILDING INSTRUCTIONS PCB V1.2...
- Page 2 01. BUILD NOTES Before you start building look through the build manual so that you’ll be familiar with the building process and you won’t run into any surprises!
- Page 3 02. BUILD 00. Orient the PCB as seen on the left 01. Solder the V2164M VCA in place (oriented to the top) 02. Solder the five TL072s Look out for their orientation! 03. Solder the single LM4040 10V IC 04. Solder the single LM4040 2.5V IC...
- Page 4 02. BUILD 05. Solder the two 1n5819 diodes The marking should be on the left! 06. Solder the single 100 ohm resistor (This one sets the jack LED brightness) This is optional depending on if you want the jack LEDs or not. 07.
- Page 5 02. BUILD 10. Solder the eight 5.1k resistors 11. Solder the two 5.6k resistors 12. Solder the three 24k resistors 13. Solder the two 49.9k resistors 14. Solder the six 100k resistors...
- Page 6 02. BUILD 15. Solder the four 1M resistors 16. Solder the two 20M resistors 17. Solder the four 47pF capacitors 18. Solder the two 100pF capacitors 19. Solder the four 560pF capacitors...
- Page 7 02. BUILD 20. Solder the six 100nF capacitors 21. Solder the four 470nF capacitors 22. Solder the two 22uF capacitors Orientation matters! Match up the silkscreen print with the shape of the parts! 23. Solder the two ferrite beads 24. Solder the six SMD LEDs Watch out for their orientation! These are optional depending on if you want the jack LEDs or not.
- Page 8 02. BUILD 25. Solder the two single pin headers These are optional depending on if you want to chain this module with other DVCAs. 26. Solder the single 1x2 pin header You could leave this if you don’t want the jack LEDs. 27.
- Page 9 DVCA is designed by David Szebenyi under Antumbra. It is based on the Mutable Instruments Veils by Olivier Gillet. www.antumbra.eu Manual by David Szebenyi (www.aman.hu) 2018 • All rights reserved!
