ALP-70
Surface Mount LED Profile
SURFACE MOUNT INSTALLATION GUIDE
Run 120V wire through ceiling
1
Remove plastic diffuser to install the LED strip
2
Peel off adhesive backing on LED strip and
3
mount onto aluminum profile, making sure
that the whole length of the strip is pressed
firmly to adhere properly.
15024 Staff Ct., Gardena CA, 90248
info@corelightingusa.com | www.corelightingusa.com
T: 888.737.9192 | F: 888.789.4643
120V WIRE
WARNING: RISK OF ELECTRICAL SHOCK
* turn off main power prior to installation
* make sure hands are dry
* never touch exposed wires
ALP70INSTALLGUIDE
|
