Command
su ipconfig <suid> <new IP> <new
subnet> <new gateway>
su linktest <suid>
su ping <suid>
su reboot <all | suid>
su sw <suid> <sw #> <on | off>
sudb add <suid> <pr|re> <mac>
sudb cirmir <<suid>|all> <cir dn> <cir up>
<mir dn> <mir up>
sudb defaultcirmir
sudb defaultcirmir <cir_dn, 0..3000> <cir_up,
0..3000> <mir_dn, 0..3000> <mir_up, 0..3000>
sudb defaultcirmir <default cir dn> <default cir
up> <default mir dn> <default mir up>
sudb delete <suid | all>
sudb dload
sudb gid <suid | all> <0..15>
sudb view
survey <search time, sec> <antenna, h | v | e>
Sw
sw 0 [<on | off>]
sw 1 [<on | off>]
sw 2 [<on | off>]
sw 3 [<on | off>]
sw 5 [<on | off>]
sw 6 [<on | off>]
sw 7 [<on | off>]
sysinfo
targetap
targetap all
targetap only <mac1, hex> [<mac2, hex>]
targetrssi
targetrssi <dBm, -90..-50>
Trango Broadband Wireless — User Manual M2400S Rev. A
Radio Description
22. Remarks
23. RF TX retry at AP, RF TX retry maxed out at AP
RF TX retry at SU, RF TX retry maxed out at SU
AP Change IP, subnet, gateway for specified SU
AP Perform linktest for specified SU
AP Request SU's ranging and RSSI information
AP Reboot a specific SU or all SUs
AP Change switch settings on specified SU
AP Add new SU to SUDB
AP Change SU's CIR/MIR settings
AP Display default CIR and MIR in SUDB
AP Change default CIR and MIR
AP Set MIR/CIR values to default values
AP Delete SU in SUDB
AP Download SUDB file from TFTP buffer and write to flash memory.
This command is used to load a text file that contains the SUDB into
the AP. This command can be useful if there are large numbers of
SUs in the sector.
AP Change SU's gid
AP Display all SUDB
AP/SU Spectrum analysis of the entire band (and near band)
<search time> = 1..10 sec per channel
Opmode "OFF" only
AP/SU Display current sw setting
AP/SU set sw #0 – enable or disable packet filter for broadcast/ multicast
packets
on = filtering
default = on
SU Enable or disable SU's autoscan AP feature
If on, SU will automatically scan each channel and antenna port
searching for AP.
default=on
SU Enable or disable SU's TCP/IP service for AP
Allows TCP/IP access to SU from AP side of network via wireless
link.
default = on
AP Enable or disable SU to SU (peer to peer) service
default = off
AP/SU Enable or disable HTTPD (browser interface)
default = on
SU Enable or disable TCP/IP service for Ethernet port while SU is in
Opmode "ON"
default = on
AP Enable or disable TCP/IP service for SU. Allows TCP/IP access to
AP from SU side of network via wireless link.
default = on
AP/SU Display system configuration
SU Display the SU current setting for target AP
SU SU will associate with any AP with the same Base ID
"all" is the default setting.
SU SU will only associate with AP with specified MAC addresses.
AP Display SU Target RSSI in dBm. This setting is used in the SU
power leveling process.
AP Change target RSSI. Note: Target RSSI must be +5 dB more than
rfrxth (RFRX Threshold).
Access
rw
ro/rw
ro/rw
rw
rw
rw
rw
ro/rw
rw
rw
rw
rw
rw
ro/rw
ro/rw
ro/rw
rw
rw
rw
rw
rw
rw
rw
ro/rw
ro/rw
rw
rw
ro/rw
rw
