H-2760
INDUSTRIAL PUSH
SWEEPER
The Kleen Sweep 27 machine is exclusively designed for
dry sweeping floors. Anything beyond its intended use
will be deemed improper and the manufacturer cannot
be held liable for damages.
The term of proper use also includes compliance
with the manufacturer's instructions about operation,
maintenance and repair.
• Apart from the information contained in this manual,
the generally applicable legal provisions for safety
and prevention of accidents must be adhered to.
• Do not put this manual aside without having read
it, even if you did already operate similar ground
cleaning equipment before. Allow yourself the time
to do so in order to save time at a later moment.
• The operator is responsible for all persons in the work
area.
• Children have to keep clear of the Kleen Sweep 27
in operation. Nobody is allowed to stay in the zone
of danger.
• Machines with known defects must not be used.
• It is important to familiarize yourself with all
accessories and controls, as well as their functions,
before you start working.
PAGE 1 OF 15
1-800-295-5510
uline.com
PROPER USE
WARNINGS
Pour le français, consulter les pages 11-15.
The Kleen Sweep 27 may be serviced and repaired
by Uline.
The following is excluded from warranty:
• Natural wear and tear after overload
• Damages caused by inexpert handling
• Unauthorized modification of the machine.
• Floor cleaning machines may only be run by
qualified personnel.
• Do not use the machine in wet and slushy areas.
• Store the machine in a dry place.
• Do not use the machine in areas where there are no
properly paved roads.
• Using the machine on public roads and places is
not recommended.
• Only qualified personnel (Uline Repairs) are
permitted to perform maintenance and repair work.
• Do not use vapor jet or high pressure cleaning
equipment to clean the machine. Use of the
machine in areas endangered by explosion hazard
is not recommended.
Para Español, vea páginas 6-10.
0715 IH-2760
