H-1336
RUBBERMAID
®
JANITOR CART
TOOLS NEEDED
Rubber
Mallet
Screwdriver
Top Shelf x 1
Shelf x 1
1.
Insert legs into holes in base. Use rubber mallet to
secure in place. (See Figure 1)
1
Figure 1
Side Legs
Base
PAGE 1 OF 6
1-800-295-5510
uline.com
Phillips
Handle x 1
Base x 1
Back Leg
N
PARTS
Side Leg x 2
ASSEMBLY
2. Place shelf over the tops of the legs and slide into
place. (See Figure 2)
Figure 2
Shelf
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Bag x 1
Screw x 6
Back Leg x 1
Washer x 6
0321 IH-1336
