Specifications; Antenna Options; Physical Interfaces - Trango Systems Access5830TM AP Specifications

Access5830 Access Point
™
subscRibeR unit compatibility/Range chaRt
Access Point / Antenna SU Part #
M5580S-FSU
m5830s-ap-60
M5800S-FSU
with 14 dBi integrated patch
M5830S-SU
antenna
M5830S-SU-EXT
Range chart for M5830S-AP-EXT dependent upon antenna selection.
* Available from Radiowaves (www.radiowavesinc.com) and Radiowaves distributors.

Specifications

Radio paRameteRs
Frequency of Operation
Channels
Modulation Format
Certification/Compliance
Receiver Sensitivity (1E10-6 BER)

antenna options

M5830S-AP-60
M5830S-AP-EXT External Antenna Options
(FCC Certified Models)
data and opeRational paRameteRs
Access Method
User Data Throughout
Format
Network Protocols
Configuration and Management
Upstream/Downstream Throughput
Bandwidth Control

physical inteRfaces

Ethernet (via shielded RJ45)
Serial (via RJ11)
Ethernet Packet
poweR paRameteRs
Power Method
Voltage Input Limits into Radio
Standard Power Supply
PoE Cat-5 Max Cable Length
Power
physical and enviRonmental
Radio Enclosure
Temperature Range
NEMA Rating
Radio Dimensions
Radio Weight
User Interfaces
Specifications are typical and subject to change without notice.
Trango broadband Wireless
14118 Stowe Drive, Suite B
San Diego, Poway, CA 92064
© 2008 Trango Systems, Inc. All rights reserved. The content herein is subject to change without further notice. DS-9004-G
SU Model
Atlas FOX 5.8 GHz
FOX5800 5.8 GHz
Access5830 Dual Band
Access5830 Dual Band External
5725 MHz to 5850 MHz (ISM Band)
6 non-overlapping channels, software selectable
Direct Sequence Spread Spectrum (DSSS) with RAKE
FCC Part 15.247, 15.407
1600 byte packets: -83 dBm, 64 byte packets: -87 dBm
Integrated patch, 14 dBi, dual polarized, 60° x 10° beamwidth
Sector antenna, 16 dBi, dual polarized, 90° x 8° beamwidth (Radiowaves part #SEC-55D-90-16)
Sector antenna, 16 dBi, horizontally polarized, 120° x 8° beamwidth (Pacfic Wireless part #SAH58-120-16)
Omni antenna, 12 dBi, vertically polarized, 360° x 7° beamwidth (Pacfic Wireless part #OD58-12)
TDD with SmartPolling™
10 Mbps
10/100 Base T
All IEEE 802.3/802.3u compliant protocols
Telnet, SNMP, TFTP, HTTP
Dynamic, automatically adjusts to suit demand
Committed Info Rate (CIR) and Maxiumum Info Rate (MIR) setting per subscriber unit
10/100 BaseT, auto-sense, auto-negotiate
9600 baud
Up to 1600 byte long packets (supports VLAN/VPN pass through)
Power-over-Ethernet (PoE) via DC voltage injected at PoE J-box
10.5 VDC – 24 VDC
120 VAC to 24 VDC adapter
300 feet on 24 AWG STP Cat-5 cable
13.4 W
All-weather, powder coated, cast aluminum with polycarbonate radome
-40° to 60° C (-40° to 140° F)
NEMA 4
12.5" x 8" x 2.75"
4 lbs.
RJ45 (shielded) and RJ11
w w w . T r a n g o B r o a d B a n d . c o m
Tel.: +1 (858) 391-0010
Fax: +1 (858) 391-0020
Email: sales@trangobroadband.com
5.8 gHz Broadband wireless Base Station
SU Antenna, Gain
Integrated, 8 dBi
External dish, AD5800-25, 25 dBi
Integrated, 15 dBi
Integrated, 18 dBi
External patch, AD5830-23-D, 23 dBi
External dish, SPD3-5.2T 30 dBi dish*
Range / Fade Margin
2 miles / 10 dB
10 miles / 14 dB
4 miles / 10dB
6 miles / 10 dB
10 miles / 10dB
18 miles / 12 dB
