Information Key

The Information key provides information at your
fingertips. The sequence of key presses is as follows:
• Outdoor Temperature (if equipped)
• Current Setpoint of Mode in Use (Heat or Cool)
• Setpoint of Mode Not Currently in Use
• Filter Status
If the filter status is expired (refer to Filter Indication section), the sequence of
• Filter Status
• Outdoor Temperature (if equipped)
• Current Setpoint of Mode in Use (Heat or Cool)
• Setpoint of Mode Not Currently in Use

Displaying Outdoor Temperature

Press once to display the outdoor
temperature (if equipped).
NOTE: If the filter status is expired, press
twice to display outdoor temperature.
Pressing
Example displays shows outdoor temperature at 50 .
23
INFORMATION KEY
key presses is as follows:
Outdoor
key once displays the outdoor temperature.
