- Page 1 Radio / Cassette St. Louis C33 Operating instructions 7 642 183 110 (FM/MW/LW/DMS) http://www.blaupunkt.com http://www.blaupunkt.com...
- Page 2 Open here Ouvrir s.v.p.
- Page 4 CONTROLS button to release the control panel Button to switch the unit on/off Volume control Cassette eject Cassette compartment FR button, fast tape winding FF button, fast tape winding Arrow buttons MENU button, to open the basic settings menu SOURCE button, to select the CC, radio and CD changer sources AUDIO button, to adjust the...
-
Page 5: Table Of Contents
Notes and accessories ... 6 Road safety ... 6 Installation ... 6 Accessories ... 6 Removable control panel ... 7 Theft protection ... 7 Detaching the control panel ... 7 Attaching the control panel ... 7 Switching on/off ... 8 Adjusting the volume ... -
Page 6: Notes And Accessories
Accessories Only use accessories approved by Blaupunkt. Amplifier All Blaupunkt and Velocity amplifiers can be used. CD changer The Blaupunkt CD changer CDC A 01 (7607 700 022) can be connected to the St. Louis C33 unit. -
Page 7: Removable Control Panel
Removable control panel Theft protection As a way of protecting your equipment against theft, the unit is equipped with a detachable control panel (release panel). Without this control panel, the car radio is worthless to a thief. Protect your equipment against theft by taking the control panel with you every time you leave your vehicle. -
Page 8: Switching On/Off
SWITCHING ON/OFF Switching on/off There are various ways of switching the unit on/off: Switching on/off using the vehicle ignition If the unit is correctly connected to the vehicle’s ignition and it was not switched off using button 2, it will switch on/off simultaneously with the ignition. -
Page 9: Mute While Telephoning
ADJUSTING THE VOLUME Setting the mute level You can set the unit’s mute volume level. Press the MENU button 8. Keep pressing the 8 until “MUTE LVL” appears in the display. Set the mute level using the buttons 8. When you have finished making your changes, press the MENU button 8 twice. -
Page 10: Tuning Into A Station
RADIO MODE Tuning into a station There are various ways of tuning to a station. Automatic seek tuning button 8. Press the The unit tunes to the next receivable station. Setting the sensitivity of station seek tuning You can choose whether to tune only to strong reception stations or to also tune to those with a weak reception. -
Page 11: Cassette Mode
Cassette mode Cassette playback If there is no cassette inserted in the unit. Insert the cassette with its open edge on the right and side A/1 facing up into the cassette com- partment 5. The side of the cassette that is facing up is then played first of all (side A/1). -
Page 12: Cd Changer Mode
CD CHANGER MODE CD changer mode You can connect a CD changer (CDC A 01) to the St. Louis C33 unit. You can obtain further information on available CD changers from your dealer. Note: Information on handling CDs, inserting CDs and operating the CD changer can be found in the operating instructions supplied with your CD changer. -
Page 13: Random Track Play (Mix)
Random track play (MIX) To play the tracks on the current CD in random order, briefly press button 4 (MIX) <. “S--MIX” appears briefly in the display. To play the tracks on all inserted CDs in random order, keep the 4 (MIX) button < pressed for longer than two seconds. -
Page 14: Clock - Time
CLOCK - TIME CLOCK - Time Displaying the time To display the time, button >. briefly press the Setting the clock Press the MENU button 8. Keep pressing the 8 until “CLOCKSET” appears in the display. button 8. Press the The time appears in the display. -
Page 15: Sound And Volume Distribution Settings
Sound and volume distribution settings Adjusting the bass To adjust the BASS, press the AUDIO button :. “BAS” appears in the display. To increase the bass, turn the volume control 3 clock- wise. To decrease the bass, turn the volume control 3 anti- clockwise. -
Page 16: Equalizer And X-Bass
SOUND AND VOLUME DISTRIBUTION SETTINGS When you have finished making your changes, wait 8 seconds, the settings are saved and the audio source display appears. EQUALIZER AND Equalizer and X-BASS X-BASS The X-BASS feature can be used to boost the bass at low volume levels. To activate X-BASS, keep the EQ/X-BASS button ;... -
Page 17: Specifications
Specifications Amplifier Output power: 4 x 15 watts sine in accordance with DIN 45 324 at 14.4 V 4 x 40 watts max. power Tuner Frequency ranges US: 87.5 - 108 MHz AM (MW): 522 - 1620 kHz 144 - 288 kHz FM mono sensitivity: 15 dBf FM frequency response:... - Page 18 01-89583 8394 210 94 12 711 01-4598830 02-369 62464 40 2085 023-565 6331 66-817 157 01-2185 11111 916-467952 08-7501810 01-8471650 02-6130 0514 01-324 8756 022-8771260 0212-3460040 708-6817188 +55-19 3745 2773 +604-6413 640 Blaupunkt GmbH CM/PSS 8 622 404 081 WWW: http://www.blaupunkt.com...
- Page 19 Radio / Cassette St. Louis C33 7 642 183 110 (FM/MW/LW) Operating instructions http://www.blaupunkt.com...
- Page 20 Open here...
- Page 22 CONTROLS button to release the control panel Button to switch the unit on/off Volume control Cassette eject Cassette compartment FR button, fast tape winding FF button, fast tape winding Arrow buttons MENU button, to open the basic settings menu SOURCE button, to select the CC and radio sources AUDIO button, to adjust the bass, treble, balance and fader...
- Page 23 Removable control panel ... 7 Theft protection ... 7 Detaching the control panel ... 7 Attaching the control panel ... 7 Switching on/off ... 8 Adjusting the volume ... 8 Setting the power-on volume ... 8 Instantaneously reducing the volume (mute) ... 8 Mute while telephoning ...
- Page 24 NOTES AND ACCESSORIES Thank you for deciding to use a Blaupunkt product. We hope you enjoy using this new piece of equipment. Please read these operating instructions before using the equipment for the first time. The Blaupunkt editors are con-...
-
Page 25: Removable Control Panel
Removable control panel Theft protection As a way of protecting your equipment against theft, the unit is equipped with a detachable control panel (release panel). Without this control panel, the car radio is worthless to a thief. Protect your equipment against theft by taking the control panel with you every time you leave your vehicle. -
Page 26: Switching On/Off
SWITCHING ON/OFF Switching on/off There are various ways of switching the unit on/off: Switching on/off using the vehicle ignition If the unit is correctly connected to the vehicle’s ignition and it was not switched off using button 2, it will switch on/off simultaneously with the ignition. -
Page 27: Mute While Telephoning
ADJUSTING THE VOLUME Setting the mute level You can set the unit’s mute volume level. Press the MENU button 8. Keep pressing the 8 until “MUTE LVL” appears in the display. Set the mute level using the buttons 8. When you have finished making your changes, press the MENU button 8 twice. -
Page 28: Tuning Into A Station
RADIO MODE Tuning into a station There are various ways of tuning to a station. Automatic seek tuning button 8. Press the The unit tunes to the next receivable station. Setting the sensitivity of station seek tuning You can choose whether to tune only to strong reception stations or to also tune to those with a weak reception. -
Page 29: Cassette Mode
Cassette mode Cassette playback If there is no cassette inserted in the unit. Insert the cassette with its open edge on the right and side A/1 facing up into the cassette com- partment 5. The side of the cassette that is facing up is then played first of all (side A/1). -
Page 30: Clock - Time
CLOCK - TIME CLOCK - Time Displaying the time To display the time, button >. briefly press the Setting the clock Press the MENU button 8. Keep pressing the 8 until “CLOCKSET” appears in the display. button 8. Press the The time appears in the display. -
Page 31: Sound And Volume Distribution Settings
SOUND AND VOLUME DISTRIBUTION SETTINGS Sound and volume distribution settings Adjusting the bass To adjust the BASS, press the AUDIO button :. “BAS” appears in the display. To increase the bass, turn the volume control 3 clock- wise. To decrease the bass, turn the volume control 3 anti- clockwise. -
Page 32: Equalizer And X-Bass
EQUALIZER AND X-BASS Equalizer and X-BASS X-BASS The X-BASS feature can be used to boost the bass at low volume levels. To activate X-BASS, keep the EQ/X-BASS button ; pressed until “XBASS ON” appears in the display. “X-BASS” appears in the display. To deactivate X-BASS, keep the EQ/X-BASS button ;... - Page 33 09-435 99236 01-4010 7320 01-89583 8394 01-4598830 02-369 6464 40 2085 023-565 6331 66-817 157 01-2185 11111 916-467952 08-7501810 01-8471650 02-6130 0514 01-324 8756 022-8771260 0212-3460040 708-6817188 +55-19 3745 2773 +604-6413 640 Blaupunkt GmbH CM/PSS 8 622 403 894 WWW: http://www.blaupunkt.com...
