- Page 1 Radio / CD / MP3 Calgary MP35 San Diego MP35 Operating instructions 7 645 170 310 7 645 190 310 http://www.blaupunkt.com...
- Page 3 CONTROLS Button to switch the device on/ off and operate the volume mute function. button for detaching the con- trol panel (release panel). button to eject a CD from the device. Volume control CD compartment AUDIO button to adjust the bass, treble, balance and fader.
-
Page 4: Table Of Contents
Notes and accessories ... 32 Removable control panel ... 33 Switching on/off ... 34 Adjusting the volume ... 35 Radio mode ... 36 Adjusting the tuner settings ... 36 Switching to radio mode ... 37 RDS functions ... 37 Selecting the waveband / memory bank ... -
Page 5: Notes And Accessories
Note The San Diego MP35 is supplied with the RC 12H remote control. Amplifiers You can use all Blaupunkt and Velocity amplifiers. CD changers You can connect the following Blaupunkt CD changers: CDC A 08, IDC A 09 and... -
Page 6: Removable Control Panel
Removable control panel Theft protection As a way of protecting your car radio against theft, the unit is equipped with a removable control panel (release pa- nel). Without this control panel, the car radio is worthless to a thief. Protect you car radio against theft by taking the control panel with you every time you leave your vehicle. -
Page 7: Switching On/Off
SWITCHING ON/OFF Switching on/off You can switch the device on/off in the following ways: Switching on/off using the vehicle ignition If the device is correctly connected to the vehicle’s ignition and it was not switched off using button 1, it will switch on/off simultaneously with the ignition. -
Page 8: Adjusting The Volume
Adjusting the volume You can adjust the volume in steps from 0 (off) to 66 (maximum). To increase the volume, button 4. press the To decrease the volume, button 4. press the Setting the power-on volume Note: The device is equipped with a time- out function. -
Page 9: Radio Mode
ADJUSTING THE VOLUME Switching the confirmation beep on/off The system will play a confirmation beep for some functions if you keep a button pressed down for longer than two sec- onds, for instance, when you assign a radio station to a station button. You can switch the beep on/off. -
Page 10: Switching To Radio Mode
Switching to radio mode If you are in CD/MP3, CD-changer or AUX mode, press the BND•TS button < button = re- press the SRC peatedly until the memory bank (e.g. “FM1”) appears in the display. RDS functions This device is equipped with an RDS radio receiver (Radio Data System). -
Page 11: Tuning Into A Station
RADIO MODE Tuning into a station There are various ways of tuning into a station. Automatic station seek tuning button 8. Press the The radio tunes into the next receiva- ble station. Tuning into stations manually You can also tune into stations manual- Note: You can only tune into stations manually if the RDS function is de-... -
Page 12: Storing Stations Automatically
Storing stations automatically (Travelstore) You can automatically store the six sta- tions providing the best reception in the region (only FM). The stations are stored in the FMT memory bank. Note: Any stations previously stored in this memory bank are deleted in the process. - Page 13 RADIO MODE You can use the PTY function to select stations of a particular programme type. PTY-EON If you specify the programme type and start seek tuning, the radio will switch from the current station to a station of the selected programme type. Notes: If the tuner does not find a station that matches the selected pro-...
-
Page 14: Optimising Radio Reception
Optimising radio reception HICUT The HICUT function improves reception during poor radio reception (only FM). If interference occurs, the interference level is cut automatically. Switching HICUT on/off Press the MENU button 7. button 8 repeat- Press the edly until “HICUT” appears in the display. -
Page 15: Traffic Information
TRAFFIC INFORMATION Traffic information Your device is equipped with an RDS- EON receiver. EON stands for En- hanced Other Network. Whenever a traffic announcement (TA) is broadcast, the system switches au- tomatically from a station that does not provide traffic reports to the appropri- ate traffic information station within the broadcasting network that does. -
Page 16: Cd Mode
To ensure the system functions proper- ly, only use CDs labelled with the com- pact disc logo. Problems might be ex- perienced when playing copy-protect- ed CDs. Blaupunkt cannot guarantee the proper functioning of copy-protect- ed CDs! Besides being able to play audio CDs on this device, you can also play CDs containing MP3 music files. -
Page 17: Random Track Play (Mix)
CD MODE Random track play (MIX) Press the 5 MIX button ;. “MIX CD” appears briefly in the display and the MIX symbol lights up. The next randomly selected track will then be played. Cancelling MIX Press the 5 MIX button ; again. “MIX OFF”... -
Page 18: Displaying Cd Text
Displaying CD text Some CDs include CD text. The CD text might contain the names of the artist, album and track. You can allow the CD text to be dis- played as scrolling text every time you switch to another track. The default dis- play will appear again after the whole CD text has been shown once. -
Page 19: Mp3 Mode
MP3 MODE MP3 mode You can also use this car sound sys- tem to play CD-Rs and CD-RWs that contain MP3 music files. Preparing an MP3-CD The various combinations of CD burn- ers, CD burning software and CD blanks may lead to problems arising with the device’s ability to play certain CDs. -
Page 20: Switching To Mp3 Mode
“002”, etc.) at the beginning of each file name - you must include the leading zeros. MP3 tracks can contain additional in- formation such as the artist, album and track names (ID3 tags). This device can display ID3 tags (version 1). When creating (encoding) MP3 files from audio files, you should use bit rates up to a maximum of 256 kbits/sec. -
Page 21: Selecting A Directory
MP3 MODE Configuring the MP3 scrolling text One of the following scrolling texts is displayed once every time the track is changed. Afterwards, the configured default display is shown. The available scrolling texts are: Directory name (“DIR NAME”) Track name (“SONG NAME”) Album name (“ALBM NAME”) Artist name (“ARTIST”) File name (“FILE NAME”) -
Page 22: Scanning Tracks (Scan)
Cancelling MIX To cancel MIX, briefly press the 5 MIX button ;. “MIX OFF” appears in the display and the MIX symbol disappears. Scanning tracks (SCAN) You can scan (briefly play) all the tracks on the CD. Press and hold down the MENU button 7 for longer than two sec- onds. -
Page 23: Cd-Changer Mode
CD-CHANGER MODE CD-changer mode Note: Information on handling CDs, in- serting CDs and operating the CD changer can be found in the oper- ating instructions supplied with your CD changer. Switching to CD-changer mode button = re- Press the SRC peatedly until “CHANGER”... -
Page 24: Random Track Play (Mix)
Cancelling REPEAT To stop the current track or current CD from being repeated, briefly press the 4 RPT button ;. “RPT OFF” appears and RPT disap- pears from the display. Random track play (MIX) To play the tracks on the current CD in random order, briefly press the 5 MIX button ;. -
Page 25: Selecting 12/24-Hour Clock Mode
REMOTE CONTROL Remote control Calgary MP35 Your car radio is equipped with an inte- grated infrared remote-control receiver. The receiver is built into the detachable control panel. You can safely and conveniently con- trol the majority of the device’s functions using a steering-wheel remote control or handheld remote control (available as optional accessories). -
Page 26: Displaying Time When Device Is Off
CLOCK TIME When you have finished adjusting the setting, press the MENU button 7. Displaying the time continuously when the device is off and the ignition is on To display the time when the device is off and the vehicle ignition is on, press the MENU button 7. - Page 27 SOUND Setting the left/right volume distribution (balance) To adjust the left/right volume distribu- tion (balance), press the AUDIO button 6. “BASS” appears in the display. button 8 repeatedly Press the until “BAL” appears in the display. button 8 to ad- Press the just the balance (right/left).
-
Page 28: X-Bass
X-BASS X-BASS You can use the X-Bass feature to boost the bass at low volume levels. The selected X-Bass setting affects all the audio sources (radio, CD/MP3, CD changer or AUX). You can set the X-BASS boost in steps ranging from 1 to 3. “XBASS OFF”... -
Page 29: External Audio Sources
You can obtain this cable (Blau- punkt no.: 7 607 897 093) from your authorised Blaupunkt dealer. Note: If no CD changer is connected, the AUX input must be activated in the menu. - Page 30 Bitte den ausgefüllten Gerätepass sicher aufbewahren! Please keep the filled-in radio pass in a safe place! Prière de conserver soigneusement la carte d’autoradio remplie ! Tenete per favore il libretto di apparecchio, debitamente riempito, in un posto sicuro! Bewaar de ingevulde apparaatpas op een veilige plaats! Vänligen förvara ifyllt apparatpass på...
- Page 31 (Mercosur) (BR) +55-19 3745 2769 Malaysia (Asia Pacific) (MAL) +604-6382 474 Gerätepass Name: Typ: Serien-Nr: Blaupunkt GmbH, Robert-Bosch-Straße 200, D-31139 Hildesheim 02/05 - CM/ASA Fax: 05121-49 4002 01-610 39 391 02-525 5263 44-898 644 09-435 99236 01-4010 7320 01-89583 8394...
- Page 32 Absatz „Programm-Typ (PTY)”. (GB) Note regarding PTY-EON reception If your Blaupunkt system switches from your chosen radio programme to another radio programme or from your chosen audio source (CD or CD changer) to a radio programme, please check whether you have activated the PTY (programme type) function.
- Page 33 "Radio". (ES) Observaciones sobre la recepción PTY-EON Si su equipo Blaupunkt cambia de la emisora de radio que está escuchando a otra, o de la fuente de sonido seleccionada (CD o cambiadiscos) a una emisora de radio, verifique si tiene activada la función PTY (tipo de programa).
- Page 34 (DK) Oplysning om PTY-EON-modtagelse Hvis din Blaupunkt radio slår fra det aktuelle radioprogram over i et andet eller fra en valgt kilde (CD eller Multi CD) over i et radioprogram, bør du tjekke om du har tændt for PTY (programtype).
- Page 35 (HU) Utasítás a PTY-EON vételhez...
- Page 36 (GR) À fi‰ÂÈÍË ÁÈ· ÙË Ï‹„Ë PTY-EON ŸÙ·Ó Ë Û˘Û΢‹ Û·˜ Blaupunkt ·ÏÏ¿˙ÂÈ · fi ¤Ó· Ú·‰ÈÔʈÓÈÎfi ÚfiÁÚ·ÌÌ· Ô˘ ·ÎÔ‡Ù Û ¤Ó· ¿ÏÏÔ Ú·‰ÈÔʈÓÈÎfi ÚfiÁÚ·ÌÌ· ‹ · fi ÌÈ·  ÈÏÂÁ̤ÓË ËÁ‹ (CD ‹ ÙÚÔÊÔ‰fiÙ˘ CD) Û ¤Ó· Ú·‰ÈÔʈÓÈÎfi ÚfiÁÚ·ÌÌ·, ÙfiÙ ÂϤÁÍÙ ·Ú·Î·ÏÒ, ¿Ó...
- Page 37 (RU) Указание по приему PTY-EON " " " "...
