- Page 1 IRIS Touch Quick Installation & Maintenance Guide Version 1.0...
- Page 2 Page 2 of 16 IRIS Touch Quick Installation & Maintenance Guide Version 1.0...
-
Page 3: Table Of Contents
Installing the IRIS Touch ....................7 6.1. Mounting ........................7 6.2. Power .......................... 7 6.3. Connections......................... 7 6.4. GSM SIM card (IRIS Touch 400 & 440) ................. 8 6.5. Dial capture ......................... 8 6.6. PIN Inputs ........................9 6.7. Expansion board ......................9 6.8. -
Page 4: Introduction
The IRIS Touch is based on Chiron’s successful IRIS Touch range of AoIP diallers with the same hardware and software used in all IRIS diallers; with the same level of security and features provided to military, governments, banks and commercial industry markets. -
Page 5: Package Contents
3. Package Contents Contents dependent on model type: Dialler board Ethernet cable (IRIS Touch 420 & 440) GSM antenna (IRIS Touch 400 & 440) Stylus RJ11 cable 18k Ohms sense resistor 4. Board Configuration... -
Page 6: Before You Start
GPRS SIM Card and Access Point Name If the installation uses GPRS then a SIM card will be required. The IRIS Touch will also need to be given a GPRS ‘Access Point Name’ (APN) and other possible configurations as shown below. These can be obtained from the SIM card provider. -
Page 7: Installing The Iris Touch
Note: For EN50131-10 compliance you must use the supplied standoff and not the self-adhesive feet. 6.2. Power The IRIS Touch dialler can be powered from a separate or Aux 9-28V DC power supply specified to delivery up to 1A current using the screw terminals indicated in Section 4 “Board Configuration”... -
Page 8: Gsm Sim Card (Iris Touch 400 & 440)
Pin 5 (GRD) 6.4. GSM SIM card (IRIS Touch 400 & 440) DO NOT FIT SIM card until after you have performed the GPRS Network Scan detailed in the Section 6.9 “Configuration” you will be prompted when to insert the SIM card. -
Page 9: Pin Inputs
6.6. PIN Inputs The IRIS Touch dialler has 4 pin inputs that can be used to generate alarm messages, if you require more than 4 pin inputs then you can fit the IRIS Touch expansion board (ordered separately). These can be: ... -
Page 10: Configuration
Note: For connections to Honeywell Galaxy or Texecom Premier on the serial integration ensure you configure the alarm panel first as this will transmit configuration to the IRIS Touch dialler. For more details on the alarm panel integration download the full panel installation manual from http://www.chironsc.com/downloads_security.html. -
Page 11: Panel Configuration
Perform full test of alarms from the alarm panel and confirm these are received at the monitoring centre. The IRIS Touch will give a visual indication of the current system status via the SYS LED. If this is yellow constant... -
Page 12: Confirm Current Status
Confirm current status The IRIS Touch will indicate “Status – ok” If the current dialler setup is all working correctly, and if the status is showing “Status – Trouble” the dialler has a trouble reported. Click on the “Status – Trouble” and Go to the option for “View Trouble Report”. -
Page 13: Specifications
53165 (Alarms & Polling), 51292 (Diagnostic & Reflashing), 10001 (Upload / Download) Alarm transmission Interface to monitoring centre IRIS Secure Apps or IRIS Management suite Dial capture interface to alarm panel Two wire interface via RJ45 socket & terminal block... - Page 14 The dialler is compliant to the requirements of European Standards: EN50131-1: 2006 & EN50131-10: 2014 EN50136-1: 2012 & EN50136-2: 2013 Security Grade 4 ATS-SP6 (IRIS Touch 400, 420 and 440), ATS-DP4 (IRIS Touch 440) / Environmental Class II EN54-21 CPR (VdS Certified) EN54-21 CPR fire approved...
- Page 15 IRIS Touch Quick Installation & Maintenance Guide Version 1.0 Page 15 of 16...
- Page 16 The future of security, secured IP by security professionals, for the professional security industry Installation and Service Engineer Support Telephone: +44 871 977 1133 (Calls are charged at 10p a minute from a BT landline. Calls from mobiles or other providers may be higher) Sales Enquiries: +41 435 080 870 Email: sales@chironsc.com www.chironsc.com...
