- Page 1 IRIS Touch Vanderbilt / Siemens SPC Panel Range Quick Installation & Maintenance Guide Version 1.1...
-
Page 2: Table Of Contents
Installing the IRIS Touch Dialler ..................6 Mounting ........................6 Power .......................... 6 Connections......................... 6 GPRS/3G SIM card (IRIS Touch 400NG or 440NG) ............9 Dial Capture ......................... 9 RS232 .......................... 9 Ethernet ........................9 Switch On and Test ...................... 9 Configuration ...................... -
Page 3: Introduction
All IRIS Touch diallers are certified as suitable for all Grade 4 systems with an Alarm Transmission System (ATS) configuration up to SP6 for single path, or ATS configuration DP4 for dual path (IRIS Touch 440NG only). The IRIS Touch is based on Chiron’s successful IRIS Touch range of AoIP diallers with the same... -
Page 4: Package Contents
3. Package Contents Contents dependent on model type: Dialler board Ethernet cable (IRIS Touch 420NG & 440NG) GPRS/3G antenna (IRIS Touch 400NG & 440NG) Stylus RJ11 cable 18k Ohms sense resistor 4. Board Configuration... -
Page 5: Before You Start
GPRS/3G SIM Card and Access Point Name If the installation uses GPRS/3G then a SIM card will be required. The IRIS Touch will also need to be given a GPRS/3G ‘Access Point Name’ (APN) and other possible configurations as shown below. These can be obtained from the SIM card provider. -
Page 6: Installing The Iris Touch Dialler
Note: For EN50131-10 compliance you must use the supplied standoff and not the self-adhesive feet. Power The IRIS Touch dialler can be powered from a separate or Aux 9-28V DC power supply specified to deliver up to 1A current using the screw terminals indicated in Section 4 “Board... - Page 7 IRIS Touch to SPC panels using Dial capture and Serial connections: Dial Capture for the Alarms: Connect the centre two wires (Red & Green) to the A & B Terminal Blocks (Polarity not important). Serial DCE Header Connection for Upload/download: Connect the Serial (DCE) connector from the Iris to the SPC Serial Port 2 (RJ45) connector.
- Page 8 IRIS Touch to SPC panels using Ethernet Connection (EDP alarm integration): Ethernet Connection for EDP alarms & Upload/download: Connect the ETH2 (RJ45) connector from the Iris to the SPC Ethernet (RJ45) connector. Page 8 of 16 IRIS Touch Quick Installation & Maintenance Guide Version 1.1...
-
Page 9: Gprs/3G Sim Card (Iris Touch 400Ng Or 440Ng)
Touch screen. Connect the board’s Micro USB connector to a laptop / PC running the IRIS Toolbox software. Download the IRIS ToolBox user guide from http://www.chironsc.com/downloads_security.html. Defaulting If at any point you want to completely default the dialler you can use the following procedure: Enter the Installer menu on the dialler touch screen and enter the installer password. - Page 10 (CSQ) of 10 or more. If the signal strength is below or close to minimum then try to reposition the antenna/IRIS Touch dialler in different location or you can use an external building or high gain antenna (if necessary), and rerun the network scan to check signal strength.
-
Page 11: Panel Configuration
To select routing of an alarm over PSTN, place an extra digit “9” in front of the Tel 2 receiver telephone number. This tells the IRIS communicator that it should route the call over PSTN if available. If there is a PABX that requires a “9”... -
Page 12: Testing
Perform full test of alarms from the alarm panel and confirm these are received at the monitoring centre. The IRIS Touch dialler will give a visual indication of the current system status via the SYS LED. If this is yellow constant... -
Page 13: Confirm Current Status
The engineer will now be able to perform the following checks: Confirm Current Status The IRIS Touch dialler will indicate “Status – ok” if the current dialler setup is all working correctly, and if the status is showing “Status – Trouble” the dialler has a trouble reported. -
Page 14: Specifications
53165 (Alarms & Polling), 51292 (Diagnostic & Reflashing), 10001 (Upload/Download) Alarm transmission Interface to monitoring centre IRIS Secure Apps or IRIS Management Suite via EN 50136-2 pass-through mode Dial capture interface to alarm panel Two wire interface via RJ45 socket or terminal block... - Page 15 (42.4V peak or 60V dc maximum) The interfaces on the IRIS Touch have the following safety classifications: ...
